Key Architecture Highlights
- Chassis form factor: R6950 G6 T10: Turin platform, integrated engine 10U height , GPU module 6U height; R6950 G6 T11: Turin platform, integrated engine 8U height , GPU module 4U height; R6950 G6 T12: Turin platform, integrated engine 6U height , GPU module 2U height
- Supported processors: Supports 2 Processors AMD EPYC 9005 Series Processor
- GPU: Support for OAM 8-GPU modules
Applications
- Enterprise computing
- Virtualization and cloud computing
- Data center
Engineering Parameters
| Chassis form factor | R6950 G6 T10: Turin platform, integrated engine 10U height , GPU module 6U height; R6950 G6 T11: Turin platform, integrated engine 8U height , GPU module 4U height; R6950 G6 T12: Turin platform, integrated engine 6U height , GPU module 2U height |
|---|---|
| Supported processors | Supports 2 Processors AMD EPYC 9005 Series Processor |
| GPU | Support for OAM 8-GPU modules |
| Memory slots | 24 memory slots supporting the DDR5 memory bar |
| Storage controller | Standard PCIe RAID card, which supports RAID 0/1/10/5/6/50/60 |
| Drive bays | Supports up to 12 Blocks 2.5 Yes. SAS / SATA / NVMe Hot-swappable Drive, Internal Supports 2 units M.2 |
| Network adapter | It supports up to 15 standard PCIe network adapters and 1 OCP network adapters that support smart network adapters. |
| PCIe Slot | 15 An outsider. Standard PCI‐E 5.0 Slot, 1 units OCP Slot |
| External interfaces | Front panel.: 1 units Standard VGA / 1 units Standard USB 2.0 And 1 units Standard USB 3.0 / 1 units RJ45 IPMI Management interface / 2 units Standard USB 3.0 / 1 Threads Ports |
| Power supply specifications | 2*12V 2700W or 3200W CRPS power supply (1+1 redundant), 6 or 5 or 4*54V 3200W dual input power supply (double input N+1 redundant) |
| Environmental requirements | operating temperature: 5oC + 35oC; operating humidity: 10%oC 90%; altitude: ≤ 3000m |
| System Dimensions | R6950 G6 T10: Machinery shelf 10U, width 447mm × high 441.7mm × depth 900mm; R6950 G6 T11: machinery shelf 8U, width 447mm × high 352.8mm × depth 900mm; R6950 G6 T12: machinery shelf 6U, width 447mm × high 263.9mm × depth 900mm |
| Cooling fans | R6950 G6 T10: wind-cooled 20*8080 fan (N+1 redundant ); R6950 G6 T11: wind-cooled 15*8080 fan (N+1 redundant ); liquid-cooled 12 or 13*8080 fan (N+1 redundant, the number of liquid-cooled fans and configuration modules are related); R6950 G6 T12: liquid-cooled 7 or 8*8080 fan (N+1 redundant, liquid-cooled fan number and configuration modules are related) |
Warranty
Public manufacturer information does not specify the warranty term applicable to our supply channel. The supply region, channel and actual warranty service are confirmed in the supply contract.
