Key Architecture Highlights
- Chassis form factor: 6U
- Fitting cabinet: 19 inches of aluminum 1400mm deep cabinet
- Supported processors: Supports 2 Processors Hygon C86-4G Series Height Performance Processor, Every Processors Supports up to 64 Core, Supports Super. Threads
Applications
- Enterprise computing
- Virtualization and cloud computing
- Data center
Engineering Parameters
| Chassis form factor | 6U |
|---|---|
| Fitting cabinet | 19 inches of aluminum 1400mm deep cabinet |
| Supported processors | Supports 2 Processors Hygon C86-4G Series Height Performance Processor, Every Processors Supports up to 64 Core, Supports Super. Threads |
| GPU | Support 8 mainstream OAM/SXM liquid-cooled GPU modules, both international and domestic |
| Memory slots | 24 units DDR5 Memory slots, Up to Run rate 5200MT/s |
| Storage controller | Support for standard and self-developed storage HBA, RAID card, SAS4.0/SAS3.0/SATA3.0/PCIe5.0/PCIe4.0 |
| Drive bays | Provides Multiple prefixes Drive bays Configuration, Supports up to 24x2.5 ” Drive bays, Supports SAS / SATA / NVMe Drive, Supports hot swapping; Provides Multiple backsets and flexibility Storage Modules Configuration, Supports up to 2x2.5 ” Drive bays, Supports SAS / SATA / NVMe Drive, Supports Hot-swappable; Internal Optional Provides 2 units SATA M.2 Slots bits |
| Shower Card | Integrated display controller |
| System management | WEB Manage the interface in Chinese, supporting IPMI 2.0, SNMP, SOL, RedFish, KVM Over IP |
| PCIe Slot | Maximum Yeah. Expansion 14 units PCIe Gen5 Slot, 1 units OCP 3.0 Slot |
| External interfaces | 4 units USB Interface (Back 2 units USB3.0, Front 1 units USB3.0+1 units USB2.0); 2 units VGA Interface (Frontend 1 units, Backend 1 units); 1 Threads Ports; 1 units IPMI GE Management interface |
| Power supply specifications | GPU nodes: up to 8 CRPS standard 54V power supply, supporting N+N redundant; computation nodes: 2 CRPS standard 12V power supply, support 1+1 redundant; power supply support Aluminum or Aluminum power supply, providing multiple specifications |
| Environmental requirements | Operating temperature: Temperature of the environment Supports 5-35 ℃; Storage temperature: -40 ℃～ + 65 ℃; Operating humidity: 8 ％～ 90 ％ RH, Non-condensing; Transport Storage Humidity: 5 ％～ 95 ％ RH, Non-condensing; Altitude Height: ≤ 5000 m. Height Out 900 At m., Every litre above sea level Height 300 m Operating temperature Lower 1 ℃. 3000 Over m Not supported Configuration Mechanical Drive |
Warranty
Public manufacturer information does not specify the warranty term applicable to our supply channel. The supply region, channel and actual warranty service are confirmed in the supply contract.
