Key Architecture Highlights
- Chassis form factor: 6U
- Supported processors: Supports 2 Processors AMD Turin / Genoa Processor, Every Processors Supports up to 192 units Cores
- Memory slots: 24 memory slots supporting the DDR5 memory bar
Applications
- Enterprise computing
- Virtualization and cloud computing
- Data center
Engineering Parameters
| Chassis form factor | 6U |
|---|---|
| Supported processors | Supports 2 Processors AMD Turin / Genoa Processor, Every Processors Supports up to 192 units Cores |
| Memory slots | 24 memory slots supporting the DDR5 memory bar |
| Storage controller | Standard PCIe RAID card, which supports RAID 0/1/10/5/6/50/60 |
| Drive bays | 1 supports up to 32 2.5 ton SAS/SATA drives (optional support for NVMe SSDs, up to 16 NVMe SSDs); 2 built-in 2 M.2 SATA SSDs ((optional) |
| PCIe Slot | ① Switched configuration: 13 standard PCIe5.0 slots (not hot-swappable); supports 10 double-width/single-width GPU accelerator cards + 1 standard card, or 8 double-width/single-width GPU accelerator cards + 5 standard cards. ② Switched configuration: 21 standard PCIe4.0 slots (not hot-swappable); supports 20 single-width half-length GPU accelerator cards + 1 standard card, or 16 single-width full-length GPU accelerator cards + 5 standard cards. ③ Pass-through configuration: 11 standard PCIe5.0/PCIe4.0 slots (not hot-swappable); supports 10 double-width/single-width GPU accelerator cards. ④ Supports 1 OCP slot (optional). |
| External interfaces | The front panel: 1 standard VGA, 1 standard USB 3.0 + 1 standard USB 2.0; the back window: 1 RJ45 IPMI management interface, 2 standard USB 3.0, 1 standard VGA, 1 series of ports |
| Power supply specifications | Supports up to 8 power supply modules, supports N+N redundant mode, supports hot swapping; optional 220V AC/240V DC; 2000W/2700W/3200W and more |
| Environmental conditions | Operating temperature: 5 ℃～ 35 ℃; Storage Temperature: -40 ℃～ 65 ℃; Operating humidity: 8 ％～ 90 ％ RH, Non-condensing; Transport Storage Humidity: 5 ％～ 95 ％ RH, Non-condensing; Altitude Height: ≤ 3000m |
| System Dimensions | 6U rack; with no side-ear and bonnet: 447 mm x 263.9mm x 900 mm; with side-ear and bonnet: 482.6 mm x 263.9mm x 913.7 mm; |
| Cooling fans | 10 8080 fans (N+1 redundant) + 6 6056 fans (N+1 redundant), supporting dynamic smart tuning |
| Weight |
Warranty
Public manufacturer information does not specify the warranty term applicable to our supply channel. The supply region, channel and actual warranty service are confirmed in the supply contract.
