Key Architecture Highlights
- Chassis form factor: 4U
- Supported processors: Support for customized asynchronous processors in high-performance areas
- Memory slots: Support mainstream RDIMM ECC memory slots
Applications
- Enterprise computing
- Virtualization and cloud computing
- Data center
Engineering Parameters
| Chassis form factor | 4U |
|---|---|
| Supported processors | Support for customized asynchronous processors in high-performance areas |
| Memory slots | Support mainstream RDIMM ECC memory slots |
| Storage controller | Supporting standard and self-developed storage HBA, RAID cards |
| Drive bays | It offers multiple pre-set drive bays configuration, supports hot swapping, and support for HDD, SSD |
| PCIe Slot | Expanded Multi-Mainstream PCIe Standard Slots |
| External interfaces | 4 units USB Interface; 2 units VGA Interface (Frontend 1 units, Backend 1 units); 1 units IPMI GE Management interface |
| Shower Card | Integrated display controller with maximum resolution of 1920 x 1080 |
| System management | WEB Manage the interface in Chinese, supporting IPMI 2.0, SNMP, SOL, RedFish, KVM Over IP |
| Power supply specifications | 2 A CRPS Standard Power supply, Supports hot swapping, Supports 1+1 Redundant Platinum. Power supply, Provides 800W ~ 2000W Multiple Specifications; Supports Multiple Power input Formula: 110/220VAC / -48VDC, 240VDC / 336VDC Power input |
| Cooling fans | 4 or 8 plug-in redundant fans, cooling system with dynamic smart fan speed |
| Supported operating systems | CGSL, Suse, Redhat, Centos, Silicon, and Red Flag operating systems are also available. |
| System Dimensions | 19 inches Airframe, 447.6mm (width) x 175mm (high) x 780mm (length), with no side ears |
| Weight | Full configuration not exceeding 60kg (without guidance) |
| Environmental requirements | The following are the operating temperatures: 5°C and 40°C; storage temperature:-40°C and 65°C; operating humidity: 8% and 90% RH, non-condensing; transportation storage Humidity: 5% and 95% RH, non-condensing; altitude:3000 m |
Warranty
Public manufacturer information does not specify the warranty term applicable to our supply channel. The supply region, channel and actual warranty service are confirmed in the supply contract.
