Key Architecture Highlights
- Chassis form factor: 2U
- Supported processors: Supports 1 or 2 AMD EPYC 9004/9005 series processors, and single processor supports up to 400W
- Memory slots: 24 units DDR5 -5600 RDIMM / L RDIMM Memory slots
Applications
- Enterprise computing
- Virtualization and cloud computing
- Data center
Engineering Parameters
| Chassis form factor | 2U |
|---|---|
| Supported processors | Supports 1 or 2 AMD EPYC 9004/9005 series processors, and single processor supports up to 400W |
| Memory slots | 24 units DDR5 -5600 RDIMM / L RDIMM Memory slots |
| Storage controller | Support for standard and self-developed storage HBA, RAID card, SAS4.0/SAS3.0/SATA3.0/PCIe5.0/PCIe4.0 |
| Drive bays | Provides Multiple prefixes Drive bays Configuration, Supports hot swapping, Supports HDD / SSD:; 8x2.5 ” Drive bays, Supports SAS / SATA / U. 2; 16x2.5 ” Drive bays, Supports SAS / SATA / U. 2; 24x2.5 ” Drive bays, Supports SAS / SATA / U. 2; 25x2.5 ” Drive bays, Supports SAS / SATA, of which 8 units Supports U. 2; 12x3.5 ” Drive bays, Supports SAS / SATA / U. 2; Provides Multiple backsets and flexibility Storage Modules Configuration, Multiple Choices, Supports hot swapping, Supports HDD / SSD:; 2x2.5 ” Drive bays, Supports SAS / SATA / U. 2, Supports up to 4 units Drive; 2x3.5 ” Drive bays, Supports SAS / SATA / U. 2, Supports up to 4 units Drive |
| Shower Card | Integrated display controller, supporting selected PCIe standard graphics cards |
| System management | WEB Manage the interface in Chinese, supporting IPMI 2.0, SNMP, RedFish, KVM Over IP |
| PCIe Slot | Maximum expansion of 12 PCIe slots (including 2 OCP 3.0 slots) |
| External interfaces | 4 USB interfaces (backward 2 USB 3.0, frontward 1 USB 3.0+1 USB 2.0); 2 VGA interfaces (front end 1, back end 1); 1 3.5MM serial ports; 1 IPMI GE management interfaces |
| Power supply specifications | 2 A CRPS Standard Power supply, Supports hot swapping, Supports 1+1 Redundant; Optional 550W/800W/1200W/1600W/2000W/2700W/3200W, Supports Height Platinum / titanium. Power supply; Supports Multiple Power input Formula: 110/220VAC / -48VDC, 240VDC / 336VDC Power input |
| Environmental requirements | Operating temperature: 5 ℃～ 40 ℃ (Operating temperature Different. Configuration Impact, For further information, please refer to the technical document description); Storage Temperature: -40 ℃～ 65 ℃; Operating humidity: 8 ％～ 90 ％ RH, Non-condensing; Transport Storage Humidity: 5 ％～ 95 ％ RH, Non-condensing; Altitude Height: ≤ 3000 m. Height Out 900 At m., Every litre above sea level Height 300 m Operating temperature Lower 1 ℃. 3000 Over m Not supported Configuration Mechanical Drive |
Warranty
Public manufacturer information does not specify the warranty term applicable to our supply channel. The supply region, channel and actual warranty service are confirmed in the supply contract.
