Key Architecture Highlights
- Form: 2U
- Supported processors: Support 1/2 path AMD Rome/Milan series processors, each supporting up to 64 cores and super threads
- Memory support: 32 DDR4-3200 RDIMM and LRDIMM memory slots
Applications
- Enterprise computing
- Virtualization and cloud computing
- Data center
Engineering Parameters
| Form | 2U |
|---|---|
| Supported processors | Support 1/2 path AMD Rome/Milan series processors, each supporting up to 64 cores and super threads |
| Memory support | 32 DDR4-3200 RDIMM and LRDIMM memory slots |
| Drive bays | It supports up to 33 2.5" or 16 3.5" + 4 2.5" SAS/SATA HDD/SSD hot-swappable drives. It supports up to 26 NVMe U.2 drives and supports 2 M.2 SATA/PCIe SSDs. |
| Storage controller | Support standard and self-developed HBA, RAID cards, support SAS 3.0/SATA 3.0/PCIe 3.0/PCIe 4.0 |
| PCIe Slot | Maximum expansion is 12 PCIe 4.0 slots (including 1 RAID card slot and 1 OCP slot), 2 dual-width GPU cards |
| External interfaces | 4 USB interfaces (2 rear USB 3.0/USB 2.0, 2 front USB 2.0), 2 VGA interfaces (front 1 and back 1), 1 RJ45 serial ports 3 GE copper ports (2 service GE interface, 1 IPMI GE management interface) |
| Shower Card | Integrated display controller with maximum resolution of 1920 x 1080 |
| Power supply specifications | 2 units CRPS Standard Power supply, Supports hot swapping, Supports 1+1 Redundant Platinum. Power supply, Provides 550W / 800W / 1200W Multiple Specifications Supports Multiple Power input Formula: 110/220VAC / -48VDC, 240VDC / 336VDC Power input |
| Cooling fans | 4 plug-in redundant fans, with cooling system that supports dynamic intelligent fan |
| System management | WEB Manage the interface in Chinese, supporting IPMI 2.0 and KVM Over IP |
| Supported operating systems | New operating systems supported by CGSL, Microsoft Windows Server, Suse, Redhat, Centos, VMWare ESXI, Linux, Red Flag and other operating systems |
| Fitting cabinet | 19 inches of aluminum 1000mm deep cabinet |
| Chassis dimensions | 19 inches Airframe, chassis dimensions: 432mm x 87.6mm x 780mm ((width x high x deep), no side ears, guides |
Warranty
Public manufacturer information does not specify the warranty term applicable to our supply channel. The supply region, channel and actual warranty service are confirmed in the supply contract.
