Key Architecture Highlights
- Chassis form factor: 2U
- Supported processors: Supports 1 Intel® xeon® 6 performance nuclear processor or a Xeon®6 energy-efficient nuclear processor
- Memory support: 12 DDR5 memory slots with a top speed of 6400MT/s
Applications
- Enterprise computing
- Virtualization and cloud computing
- Data center
Engineering Parameters
| Chassis form factor | 2U |
|---|---|
| Supported processors | Supports 1 Intel® xeon® 6 performance nuclear processor or a Xeon®6 energy-efficient nuclear processor |
| Memory support | 12 DDR5 memory slots with a top speed of 6400MT/s |
| Storage controller | Support for RAID 0/1/5/6/10/50/60 and other support for power outage protection |
| Local storage | Supports up to 45 2.5 ton drive bays or 20 3.5 ton drive bays + 4 2.5 ton drive bays; supports up to 23 E1.S[1]/E3.S1 |
| Network interfaces | It supports 1 OCP 3.0 interface, PCIe 5.0 x8, and optional expansion to PCIe 5.0 x16. |
| PCIe Expansion slots | Up to Supports 12 units PCIe Expansion slots, 1 units OCP Special purpose Slot, 11 units Standard PCIe Slot |
| External interfaces | 5 units USB Interface (2 A rear. USB3.0, 1 Front USB3.0, 1 Internal USB3.0, 1 Front USB2.0); 2 units VGA Interface (Frontend 1 units, Backend 1 units); 1 Threads Ports (TYPE-C) |
| Management interface | 1 Independent GE management network Ports |
| Supported operating systems | It is compatible with the current mainstream server operating systems: Microsoft Windows Sever, Red Hat Enterprise Linux, SUSE Enterprise Linux, VMware ESXi, Ubuntu and others. |
| Power supply specifications | Supports 1+1 Hot-swappable Redundant power supply; Optional 800W/1300W/1600W/2000W/2700W/3200W, Supports Height Platinum / titanium. Power supply; Supports 110V/220V Communications / 240V/336V Height Press the flow. / -48V Straightstream |
| Cooling fans | Maximum 6 sets of efficient fans, N+1 redundant and intelligent cooling system |
| Environmental requirements | Operating temperature: + 5 ºC～ + 45 ºC (Operating temperature Different. Configuration Impact, For further information, please refer to the technical document description); Storage temperature: -40 ºC～ + 65 ºC; Operating humidity: 8 ％～ 90 ％ RH, Non-condensing; Transport Storage Humidity: 5 ％～ 95 ％ RH, Non-condensing; Altitude Height: ≤ 3000 m. Height Out 900 At m., Every litre above sea level Height 300 m Operating temperature Lower 1 ℃. 3000 Over m Not supported Configuration Mechanical Drive |
Warranty
Public manufacturer information does not specify the warranty term applicable to our supply channel. The supply region, channel and actual warranty service are confirmed in the supply contract.
