Key Architecture Highlights
- Controller Number: 2~32
- Supported processors: High-performance state-owned multi-core processor
- Maximum Cache / Double Control: 3TB
Applications
- Enterprise data storage
- Virtualized storage
- Data protection
Engineering Parameters
| Controller Number | 2~32 |
|---|---|
| Supported processors | High-performance state-owned multi-core processor |
| Maximum Cache / Double Control | 3TB |
| Maximum Interface Number / Double Control | Frontend Interface: 32 units 10GE / 40 units 25GE / 32 units 32Gb FC / 16 units 100GE / 16 units 200GE; Backend Interface: 24 units 48Gb HD-miniSAS / 12 units 100Gb ETH |
| Master control cabinet Drive Number | 24 units of NVMe SSD |
| Maximum Drive Number / Double Control | Full NVMe SSD configuration: dual controlled 456 NVMe SSD, 32 controlled 4992 NVMe SSD; full SAS SSD configuration: dual controlled 864 SAS SSD, 32 controlled 9216 SAS SSD |
| Drive Specifications | The 2.5NVMe SSD is 1.92TB, 3.84TB, 7.68TB, 15.36TB; the 2.5NSAS SSD is 1.92TB, 3.84TB, 7.68TB, 15.36TB. |
| Power-loss protection | C2F permanent data off power protection technology |
| RAID Supports | 1, 10, 5, 6, 50, 60, RAID-TP, EEP |
| Supports LUN Count | 60000 |
| Connect Host Count | 8192 |
| Single Rollshots. Count | 2048 |
| Quickshot Count | 8192 |
| Storage Service agreements | iSCSI, NVMe over RoCE, FC, NFS, CIFS, FTP, SFTP, POSIX |
| Other Software Features | Quick-photography, cloning, scroll migration, scroll copying, automated streamlining, QoS, weighting, compression, double live, remote replication, overall wear balance, silent error detection and repair, quota, WORM |
| System management | Support for independent Ethernet ports, WebUI/CLI management interfaces; support for SNMP, SMI-S, RESTful API protocol management interfaces; support for multiple virtualization platform storage interfaces such as OpenStack Cinder/Malina, Kubernetes CSI, VMware and others. |
Warranty
Public manufacturer information does not specify the warranty term applicable to our supply channel. The supply region, channel and actual warranty service are confirmed in the supply contract.
