Key Architecture Highlights
- Capacity: 3.84 TB
- Interface and speed: PCIe Gen5 × 4, NVMe 2.0, single ports
- Form factor: E3.S 1T
Applications
- Virtual server
- The database of OLTP
- Software defines storage
- Full flash array
- Cache and layered storage
- AI and Machine Learning
Engineering Parameters
| Capacity | 3.84 TB |
|---|---|
| Interface and speed | PCIe Gen5 × 4, NVMe 2.0, single ports |
| Form factor | E3.S 1T |
| Flash type | 3D eTLC |
| Sustained read/write performance | Maximum continuous reading order: 14,900 MB/s Maximum continuous writing order: 8,500 MB/s |
| Random read/write performance | The maximum continuous random reading of 3,300,000 IOPS and the maximum continuous random writing of 350,000 IOPS |
| Read/write latency | Average reading delay: 60 μs Average writing delay: 10 μs |
| Write endurance | The number of times a day the entire disk is written: 1 DWPD, rated total write-up (TBW):7,000 TB |
| Data protection and security | The security version: Standard ISE |
| Reliability | The average time of failure (MTBF) is: 2,500,000 h |
| Power consumption | Average power consumption of vacuum pumps: 5 W |
| Operating temperature | 0–70°C |
| Dimensions | The maximum height: 7.65 mm (0.3 in) maximum width: 76.2 mm (3 in) maximum depth: 113.1 mm (4.45 in) |
| Reference weight | 115 g(0.254 lb) |
Warranty
The manufacturer's specification lists the 5 limited warranty; actual qualifications, deadlines and nominal entry limits are based on the manufacturer's serial number queries, official terms and delivery confirmation results.
