Key Architecture Highlights
- Configurable AP Count Upper limit: 4,096
- Interface: 4 x 10GE SFP+ ports 8 x 1GE SFP/RJ45 combo ports, shared with one 10/100/1000BASE-T port Port 1 can be used as an out-of-band management port 1 x RJ45 console port 2 x USB ports
- Maximum Power consumption: 70 W
Applications
- Corporate network
- Campus and office networks
Engineering Parameters
| Configurable AP Count Upper limit | 4,096 |
|---|---|
| Interface | 4 x 10GE SFP+ ports 8 x 1GE SFP/RJ45 combo ports, shared with one 10/100/1000BASE-T port Port 1 can be used as an out-of-band management port 1 x RJ45 console port 2 x USB ports |
| Power input | 2 x RG-PA70I 70 W AC power modules A power module is delivered with the main unit. You can buy one more optionally. Power input: 100 V AC to 240 V AC, 50 Hz to 60 Hz, 10 A (steady state) Power output: 12 V DC, 5.83 A |
| Maximum Power consumption | 70 W |
| Rack height | 1 RU |
| Device dimensions (Width × Depth × Height) | 440 mm x 340 mm x 43.6 mm (17.32 in. x 13.39 in. x 1.72 in.) |
| Weight | Main unit:5.9 kg (13.01 lbs) A power module is delivered with the main unit. Power module: 0.4 kg (0.88 lbs) Shipping: 7.03 kg (15.50 lbs) |
| Environmental requirements | Storage temperature: –40°C to +70°C (–40°F to +158°F) Storage humidity: 5% to 95% RH (non-condensing) Storage altitude: –500 m to +4,000 m (–1,640.42 ft. to +13,123.36 ft.) Operating temperature: 0°C to +45°C (32°F to 113°F) Operating humidity: 10% to 90% RH (non-condensing) Operating altitude: –500 m to +3,000 m (–1,640.42 ft. to +9,842.52 ft.) Note: At an altitude in the range of 1,800–3,000 m (5,905.51–9,842.52 ft.), every time the altitude increases by 220 m (721.78 ft.), the maximum temperature decreases by 1°C (1.8°F). |
| System memory | 8 GB DRAM, eMMC 4 GB |
Warranty
Public manufacturer information does not specify the warranty term applicable to our supply channel. The supply region, channel and actual warranty service are confirmed in the supply contract.
