Key Architecture Highlights
- Service ports: 8 x 10/100/1000BASE-T ports, ports 3 to 8 supporting PoE/PoE+ 2 x 1G/2.5G/5GBASE-T ports, ports 1 to 2 supporting PoE/PoE+ 2 x 1GE/10GE SFP+ ports
- Management Ports: 1 x RJ45 console port
- System Switching capacity: 76 Gbps
Applications
- Corporate network
- Campus and office networks
Engineering Parameters
| Service ports | 8 x 10/100/1000BASE-T ports, ports 3 to 8 supporting PoE/PoE+ 2 x 1G/2.5G/5GBASE-T ports, ports 1 to 2 supporting PoE/PoE+ 2 x 1GE/10GE SFP+ ports |
|---|---|
| Management Ports | 1 x RJ45 console port |
| System Switching capacity | 76 Gbps |
| Processor | Single-core CPU, with the clock speed of 1 GHz |
| Flash Storage | 256 MB |
| Memory | 512 MB DDR3 |
| Switch buffer | 1.5 MB |
| Device dimensions (Width × Depth × Height) | 210 mm x 235 mm x 55 mm (8.27 in. x 9.25 in. x 2.17 in.) |
| Rack height | 1 RU |
| Net weight | 2.33 kg (5.14 lbs) |
| Power input | 1 x fixed power module |
| Power supply Input | AC input ● Rated input voltage: 200 V AC to 240 V AC, 50/60 Hz ● Maximum input voltage: 180 V AC to 264 V AC, 47 Hz to 63 Hz ● Maximum input current: 3 A |
| Maximum Output Power | Fixed power supply: 150 W |
| Maximum Power consumption | 25 W (without PoE load) 150 W (full PoE load) |
Warranty
Public manufacturer information does not specify the warranty term applicable to our supply channel. The supply region, channel and actual warranty service are confirmed in the supply contract.
