Key Architecture Highlights
- Modules Slot: 2 x supervisor module slots 6 x line card slots 4 x power module slots 2 x fan module slots
- Master Module: The main control module: M7808C-CM II Main control module: M7808C-CM-X
- Swap Network Module: Swap Network Module: M7808C-CM II (switch fabric module integrated with supervisor module); Swap Network Module: M7808C-CM-X (switch fabric module integrated with supervisor module)
Applications
- Campus network
- Enterprise network access and aggregation
Engineering Parameters
| Modules Slot | 2 x supervisor module slots 6 x line card slots 4 x power module slots 2 x fan module slots |
|---|---|
| Master Module | The main control module: M7808C-CM II Main control module: M7808C-CM-X |
| Swap Network Module | Swap Network Module: M7808C-CM II (switch fabric module integrated with supervisor module) Swap Network Module: M7808C-CM-X (switch fabric module integrated with supervisor module) |
| Service line cards | Service line cards: M7808C-CM II supports the following 9 modules: ● M7800C-32XS4QXS-DA ● M7800C-24GT24SFP4XS-EB ● M7800C-24SFP/12GT4XS-EB ● M7800C-48GT4XS-EB ● M7800C-48SFP4XS-EB ● M7800C-48GT-FA ● M7800C-48SFP-FA ● M7800C-48XS-FB ● M7800C-8CQ-FB * 1 Service line cards: M7800C-48GT4XS-XA M7800C-48SFP4XS-XA M7800C-24GT8SFP8XS-XA M7800C-32XS-XA M7800C-52XS-XB M7800C-12CQ-XB M7800C-48XT-P-XB M7800C-8SFG-XB M7800C-8SFX-XB |
| Power supply specifications | Power supply modules: RG-PA600I-F RG-PA1600I-F power supply specifications:4 x pluggable power modules power input: RG-PA600I-F (AC input): ● Rated input voltage: 100 V AC to 240 V AC, 50/60 Hz ● Maximum input voltage: 90 V AC to 264 V AC, 47 Hz to 63 Hz ● Maximum input current: 10 A RG-PA1600I-F (AC input): ● Rated input voltage: 100 V AC to 240 V AC, 50/60 Hz ● Maximum input voltage: 90 V AC to 264 V AC, 47 Hz to 63 Hz ● Maximum input current: 16 A |
| Fan Modules | The first is the "Fan Module:M08-FAN (pre-installed 2)". |
| Modules Management interface | Module management interface: M7808C-CM II: ● 1 x RJ45 console port ● 1 x RJ45 MGMT port Module management interface: M7808C-CM-X: ● 1 x RJ45 console port ● 1 x RJ45 MGMT port |
| USB Interface | USB Interface: M7808C-CM II: 2 x USB 2.0 ports (no capacity limit, 2G/4G/8G/16G/32G capacity tested) USB Interface: M7808C-CM-X: 1 x USB 2.0 port (no capacity limit, 2G/4G/8G/16G/32G capacity tested) |
| Processor | ● M7808C-CM II: quad-core CPU, each core with the clock speed of 1.5 GHz Line card ● EB card: quad-core CPU, each core with the clock speed of 1.0 GHz ● DA/FA/FB card: quad-core CPU, each core with the clock speed of 1.5 GHz processor : Supervisor module: ● M7808C-CM-X: quad-core processor, each core 2.2 GHz Line card: ● XA/XB series line card: quad-core processor, each core 2.2 GHz |
Warranty
Public manufacturer information does not specify the warranty term applicable to our supply channel. The supply region, channel and actual warranty service are confirmed in the supply contract.
