Key Architecture Highlights
- Modules Slot: 2 x power module slots 3 x fan module slots 1 x expansion module slot
- Expansion Modules: M7600-2CQ M7600-4GT4VS
- Fan Modules: S7620-FAN I-F
Applications
- Campus network
- Enterprise network access and aggregation
Engineering Parameters
| Service ports | The fixed service ports: 20 x SFX ports (160 x 10GE logical channels) 2 x 40GE/100GE QSFP28 ports (supporting 4 x 10GE/4 x 25GE) Module service ports: M7600-4GT4VS: ● 4 x 10/100/1000BASE-T ports ● 4 x 1GE/10GE/25GE SFP28 ports M7600-2CQ: ● 2 x 40GE/100GE QSFP28 ports |
|---|---|
| Modules Slot | 2 x power module slots 3 x fan module slots 1 x expansion module slot |
| Expansion Modules | M7600-2CQ M7600-4GT4VS |
| Power supply specifications | Power supply modules: RG-PA550I II-F power supply specifications :2 x pluggable power modules power input: RG-PA550I II-F (AC input): - Rated input voltage: 100 V AC to 240 V AC, 50/60 Hz - Maximum input voltage: 90 V AC to 264 V AC, 47 Hz to 63 Hz - Rated input current: 3.5 A to 7.2 A - Maximum input current: 7.2 A |
| Fan Modules | S7620-FAN I-F |
| Management interface | 1 x RJ45 console port 1 x RJ45 MGMT port |
| USB Interface | 1 x USB 2.0 port |
| Packet forwarding rate | 2976 Mpps |
| System Switching capacity | 4 Tbps |
| Processor | Quad-core CPU, each core with the clock speed of 2.0 GHz |
| Flash Storage | 8 GB |
| Memory | 4 GB DDR4 |
| Switch buffer | 36 MB |
| Maximum Output Power | RG-PA550I II-F: 550 W |
| Modules Power consumption | 450 W |
| Chassis dimensions | Chassis dimensions (width x depth x height):442 mm x 388 mm x 88 mm (17.40 in. x 15.28 in. x 3.46 in.) rack height:2 RU |
| Weight | 11.02 kg (24.29 lbs, with 3 fan modules) |
| Temperature range | Operating temperature: 0°C to 45°C (32°F to 113°F) Storage temperature: --40°C to +70°C (--40°F to +158°F) Note: At an altitude between 1,800 m (5,905.51 ft.) and 5,000 m (16,404.20 ft.), every time the altitude increases by 220 m (721.78 ft.), the maximum temperature decreases by 1°C (1.8°F). |
Warranty
Public manufacturer information does not specify the warranty term applicable to our supply channel. The supply region, channel and actual warranty service are confirmed in the supply contract.
