Key Architecture Highlights
- Chassis form factor and dimensions: 2 RU
- Weight: 14 kg (30.86 lbs., a chassis with two power modules and three fan modules)
- Switching capacity: 6.4 Tbps
Applications
- Data center network
- Connecting business data
Engineering Parameters
| Chassis form factor and dimensions | 2 RU |
|---|---|
| Weight | 14 kg (30.86 lbs., a chassis with two power modules and three fan modules) |
| Switching capacity | 6.4 Tbps |
| Packet forwarding rate | 2030 Mpps |
| Management interface | 1 x RJ45 console port 1 x RJ45 MGMT port |
| USB Interface | 1 x USB 2.0 port (Type A connector) |
| Power consumption | Maximum power consumption: 600 W Typical power consumption: 455 W Static power consumption: 202 W |
| Power supply specifications | RG-PA800I-F (AC input): Rated input voltage: 100 V AC to 127 V AC, 200 V AC to 240 V AC, 50 Hz/60 Hz Maximum input voltage: 90 V AC to 140 V AC, 180 V AC to 264 V AC, 47 Hz to 63 Hz Rated input current: 10 A to 5 A (100 V AC to 240 V AC) Power port type: C14 RG-PA800I-F (HVDC input): Rated input voltage: 240 V DC Maximum input voltage: 180 V DC to 310 V DC Rated input current: 5 A Power port type: C14 RG-PD800I-F (DC input): Rated input voltage: –48 V DC Maximum input voltage: –36 V DC to –72 V DC Rated input current: 23 A Power port: three-pin power connector |
| Temperature range | Operating temperature: 0°C to 40°C (32°F to 104°F) Storage temperature: –40°C to +70°C (–40°F to +158°F) Note: At altitudes ranging from 2000 m (6561.68 ft.) to 5000 m (16,404.20 ft.), the maximum temperature decreases by 1°C (1.8°F) for every 200 m (656.17 ft.) increase in elevation. |
| Humidity range | Operating humidity: 10% RH to 90% RH (non-condensing) Storage humidity: 5% RH to 95% RH (non-condensing) |
| Altitude range | Operating altitude: ≤ 5,000 m (16,404.20 ft.) Storage altitude: ≤ 5000 m (16,404.20 ft.) |
| Cooling method | Air cooling, front-to-rear airflow (port-side intake) |
Warranty
Public manufacturer information does not specify the warranty term applicable to our supply channel. The supply region, channel and actual warranty service are confirmed in the supply contract.
