Key Architecture Highlights
- Service ports: 48 x 100M/1G/2.5G/5GE/10G RJ45 ports with auto-negotiation 4 x 10G/25G SFP28 ports 2 x 40G/100G QSFP28 ports
- Modules Slot: 3 x fan module slots 2 x power module slots
- Management interface: 1 x MGMT port 1 x console port
Applications
- Campus network
- Enterprise network access and aggregation
Engineering Parameters
| Service ports | 48 x 100M/1G/2.5G/5GE/10G RJ45 ports with auto-negotiation 4 x 10G/25G SFP28 ports 2 x 40G/100G QSFP28 ports |
|---|---|
| Modules Slot | 3 x fan module slots 2 x power module slots |
| Power supply specifications | Power supply modules: RG-PA600I-P-F RG-PA1000I-P-F power input: RG-PA600I-P-F (AC input): ● Rated input voltage: 100 V AC to 240 V AC ● Maximum input voltage: 90 V AC to 264 V AC ● Frequency: 50 Hz/60 Hz ● Rated current per circuit: 8 A RG-PA1000I-P-F (AC input): ● Rated input voltage: 100 V AC to 240 V AC ● Maximum input voltage: 90 V AC to 264 V AC ● Frequency: 50 Hz/60 Hz ● Rated current per circuit: 8 A |
| Management interface | 1 x MGMT port 1 x console port |
| USB Interface | 1 x USB 2.0 port |
| Switching capacity | 1.56 Tbps |
| Packet forwarding rate | 915 Mpps |
| PoE Power input | Ports 1 to 48 support PoE/PoE+ power supply. Ports 1 to 24 support PoE++ power supply. Maximum output power of a port: 90 W |
| Maximum Power consumption | Without PoE load: 280 W Full PoE load: 1,480 W |
| Chassis dimensions | 442 mm x 420 mm x 44 mm (17.40 in. x 16.54 in. x 1.73 in.) |
| Fan Modules | Fan module redundancy, hot swapping, fan speed adjustment, and fan fault alarms |
| Temperature range | Operating temperature: 0°C to 45°C (32°F to 113°F) Storage temperature: --40°C to +70°C (--40°F to +158°F) |
| Humidity range | Operating humidity: 10% to 90% RH (non-condensing) Storage humidity: 5% to 95% RH (non-condensing) |
Warranty
Public manufacturer information does not specify the warranty term applicable to our supply channel. The supply region, channel and actual warranty service are confirmed in the supply contract.
