Key Architecture Highlights
- Modules Slot: 2 x power module slots 2 x fan module slots
- Fan Modules: M1SFAN I-F (pre-installed 2)
- Management interface: 1 x RJ45 console port 1 x RJ45 MGMT port
Applications
- Enterprise campus networks
- Network access and aggregation
Engineering Parameters
| Service ports | 20 x 1GE/2.5GE/10GE SFP+ ports 4 x 10GE/25GE SFP28 ports 2 x 40GE QSFP+ ports (1 x 40GE port can be split into 4 x 10GE ports) Note: One switch provides a maximum of 32 x 10GE ports |
|---|---|
| Modules Slot | 2 x power module slots 2 x fan module slots |
| Power supply specifications | Power supply Modules: RG-PA150IB-F Power supply specifications: 2 x pluggable power modules Power input: RG-PA150IB-F (AC input): ● Rated input voltage: 100 V AC to 240 V AC, 50/60 Hz ● Maximum input voltage: 90 V AC to 264 V AC, 47 Hz to 63 Hz ● Maximum input current: 3 A RG-PD150IB-F (DC input): ● Rated input voltage: –48 V DC to –60 V DC ● Maximum input voltage: –36 V DC to –75 V DC ● Maximum input current: 5 A |
| Fan Modules | M1SFAN I-F (pre-installed 2) |
| Management interface | 1 x RJ45 console port 1 x RJ45 MGMT port |
| USB Interface | 1 x USB 2.0 port |
| Processor | Single-core CPU, with the clock speed of 1.25 GHz |
| Flash Storage | 1 GB (storing boot software for 1+1 boot redundancy) |
| Memory | 1 GB, 32-bit width, 4-bit ECC |
| Switch buffer | 4 MB |
| Maximum Output Power | RG-PA150IB-F: 150 W RG-PD150IB-F: 150 W |
| Maximum Power consumption | 85 W |
| Chassis form factor and dimensions | Chassis dimensions (Width × Depth × Height): 440 mm x 330 mm x 43.6 mm (17.3 in. x 12.99 in. x 1.72 in.) Rack height: 1 RU |
| Weight | 4.6 kg (10.14 lbs, with two fan modules) |
| Temperature range | Operating temperature: 0°C to 50°C (32°F to 122°F) Storage temperature: –40°C to +70°C (–40°F to +158°F) Note: At an altitude between 3,000 m (9,842.52 ft.) and 5,000 m (16,404.20 ft.), every time the altitude increases by 220 m (721.78 ft.), the maximum temperature decreases by 1°C (1.8°F). |
Warranty
Public manufacturer information does not specify the warranty term applicable to our supply channel. The supply region, channel and actual warranty service are confirmed in the supply contract.
