Key Architecture Highlights
- Service ports: 24 x 10/100/1000BASE-T ports 8 x 1GE/10GE SFP+ ports
- Modules Slot: 1 x expansion module slot 2 x power module slots
- Expansion Modules: M5000X-4XS2CQ Note: The V1.X switch needs to be upgraded to version 12.5(4)B0701 or later to support the expansion module.
Applications
- Corporate network
- Campus and office networks
Engineering Parameters
| Service ports | 24 x 10/100/1000BASE-T ports 8 x 1GE/10GE SFP+ ports |
|---|---|
| Modules Slot | 1 x expansion module slot 2 x power module slots |
| Expansion Modules | M5000X-4XS2CQ Note: The V1.X switch needs to be upgraded to version 12.5(4)B0701 or later to support the expansion module. |
| Power supply Modules | RG-PA150IB-F RG-PD150IB-F |
| Fan Modules | Not Supported |
| Management Ports | 1 x RJ45 console port 1 x RJ45 MGMT port |
| USB Interface | 1 x USB 2.0 port |
| System Switching capacity | 826 Gbps |
| Processor | Dual-core CPU, each core with the clock speed of 1.2 GHz |
| Flash Storage | 4 GB eMMC |
| Memory | 1 GB |
| Switch buffer | 4 MB |
| Power input | 2 x pluggable power modules |
| Power supply Input | RG-PA150IB-F (AC input): ● Rated input voltage: 100 V AC to 240 V AC, 50/60 Hz ● Maximum input voltage: 90 V AC to 264 V AC, 47 Hz to 63 Hz ● Maximum input current: 3 A RG-PD150IB-F (DC input): ● Rated input voltage: –48 V DC to –60 V DC ● Maximum input voltage: –36 V DC to –75 V DC ● Maximum input current: 5 A |
| Maximum Output Power | RG-PA150IB-F: 150 W RG-PD150IB-F: 150 W |
| Maximum Power consumption | 60 W (excluding expansion modules) 85 W (including expansion modules) |
| Device dimensions (Width × Depth × Height) | 440 mm x 340 mm x 44 mm (17.32 in. x 13.39 in. x 1.73 in.) |
| Rack height | 1 RU |
Warranty
Public manufacturer information does not specify the warranty term applicable to our supply channel. The supply region, channel and actual warranty service are confirmed in the supply contract.
