Key Architecture Highlights
- Management Ports: 1 x RJ45 console port
- USB Interface: 1 x USB 2.0 port
- Switching capacity: 176 Gbps / 336 Gbps
Applications
- Corporate network
- Campus and office networks
Engineering Parameters
| Management Ports | 1 x RJ45 console port |
|---|---|
| USB Interface | 1 x USB 2.0 port |
| Switching capacity | 176 Gbps / 336 Gbps |
| Switch buffer | 4 MB |
| Processor | Dual-core CPU, each core with the clock speed of 1.0 GHz |
| Flash Storage | 512 MB |
| Memory | DDR4 1GB |
| Device dimensions (Width × Depth × Height) | 442 mm x 220 mm x 43.6mm (17.40 in. x 8.66 in. x 1.72 in.) |
| Rack height | 1 RU |
| Net weight | 4.0 kg (8.82 lbs) |
| Installation method | Mounting on a workbench/wall or in a rack (cabinet) |
| Power input | 1 x fixed power supply |
| Power supply Input | AC input ● Rated input voltage: 100 V AC to 240 V AC, 50/60Hz ● Maximum input voltage: 90 V AC to 264 V AC ● Maximum input current: 6 A |
| Maximum Output Power | Built-in power supply: 460 W |
| Maximum Power consumption | 52 W (without PoE load) 460 W (full PoE load) |
| Temperature requirements | Operating temperature: 0°C to 45°C (32°F to 113°F) Storage temperature: –40°C to +70°C (–40°F to +158°F) Note: At an altitude between 1,800 m (5,905.51 ft.) and 5,000 m (16,404.20 ft.), every time the altitude increases by 220 m (721.78 ft.), the maximum temperature decreases by 1°C (1.8°F). |
| Humidity requirements | Operating humidity: 10% to 90% RH (non-condensing) Storage humidity: 5% to 95% RH (non-condensing) |
| Altitude range | Operating altitude: -500 m to +5,000 m (-1640.42 ft. to +16,404.20 ft.) Storage altitude: -500 m to +5,000 m (-1640.42 ft. to +16,404.20 ft.) |
Warranty
Public manufacturer information does not specify the warranty term applicable to our supply channel. The supply region, channel and actual warranty service are confirmed in the supply contract.
