Key Architecture Highlights
- Service ports: 48 x 1GE SPF ports 4 x 1GE/10GE SFP+ ports
- Modules Slot: 2 x power module slots
- Power supply Modules: RG-PA150IB-F RG-PD150IB-F
Applications
- Corporate network
- Campus and office networks
Engineering Parameters
| Service ports | 48 x 1GE SPF ports 4 x 1GE/10GE SFP+ ports |
|---|---|
| Modules Slot | 2 x power module slots |
| Power supply Modules | RG-PA150IB-F RG-PD150IB-F |
| Management Ports | 1 x RJ45 console port 1 x RJ45 MGMT port |
| USB Interface | 1 x USB 2.0 port |
| System Switching capacity | 211 Gbps |
| Processor | Dual-core CPU, each core with the clock speed of 1.2 GHz |
| Flash Storage | 2 GB |
| Memory | 1 GB |
| Switch buffer | 3 MB |
| Device dimensions (Width × Depth × Height) | 442.0 mm x 420.0 mm x 43.6 mm (17.40 in. x 16.54 in. x 1.72 in.) |
| Rack height | 1 RU |
| Net weight | 4.5 kg (9.92 lbs) |
| Power input | 2 x pluggable power modules |
| Power supply Input | RG-PA150IB-F (AC input) ● Rated input voltage: 100 V AC to 240 V AC, 50/60 Hz ● Maximum input voltage: 90 V AV to 264 V AC, 47 Hz to 63 Hz ● Maximum input current: 3 A RG-PD150IB-F (DC input): ● Rated input voltage: –48 V DC to –60 V DC ● Maximum input voltage: –36 V DC to –75 V DC ● Maximum input current: 5 A / |
| Maximum Output Power | RG-PA150IB-F: 150 W RG-PD150IB-F: 150 W |
| Maximum Power consumption | 108 W |
| Temperature requirements | Operating temperature: 0°C to 45°C (32°F to 113°F) Storage temperature: –40°C to +70°C (–40°F to +158°F) Note: At an altitude between 1,800 m (5,905.51 ft.) and 5,000 m (16,404.20 ft.), every time the altitude increases by 220 m (721.78 ft.), the maximum temperature decreases by 1°C (1.8°F). |
Warranty
Public manufacturer information does not specify the warranty term applicable to our supply channel. The supply region, channel and actual warranty service are confirmed in the supply contract.
