Key Architecture Highlights
- Service ports: 10 x 10/100/1000BASE-T ports 2 x 1GE/2.5GE SFP ports
- Management Ports: 1 x RJ45 console port
- USB Interface: 1 x USB port
Applications
- Corporate network
- Campus and office networks
Engineering Parameters
| Service ports | 10 x 10/100/1000BASE-T ports 2 x 1GE/2.5GE SFP ports |
|---|---|
| Management Ports | 1 x RJ45 console port |
| USB Interface | 1 x USB port |
| System Switching capacity | 36 Gbps |
| Processor | Single-core CPU, with the clock speed of 1.2 GHz |
| Flash Storage | 64 MB |
| Memory | 512 MB DDR4 |
| Switch buffer | 512 KB |
| Device dimensions (Width × Depth × Height) | 260.0 mm x 170.0 mm x 43.6 mm (10.24 in. x 6.69 in. x 1.72 in.) |
| Rack height | 1 RU |
| Net weight | 2.0 kg (4.41 lbs) |
| Installation method | Mounting on a workbench/wall or in a rack (cabinet) |
| Power input | 1 x fixed power supply |
| Power supply Input | AC input ● Rated input voltage: 100 V AC to 240 V AC, 50/60 Hz ● Maximum input voltage: 90 V AC to 264 V AC, 47 Hz to 63 Hz ● Maximum input current: 0.6 A |
| Maximum Output Power | Fixed power supply: 16 W |
| Maximum Power consumption | 16 W |
| Temperature requirements | Operating temperature: 0°C to 45°C (32°F to 113°F) Storage temperature: –40°C to +70°C (–40°F to +158°F) Note: At an altitude between 1,800 m (5,905.51 ft.) and 5,000 m (16,404.20 ft.), every time the altitude increases by 220 m (721.78 ft.), the maximum temperature decreases by 1°C (1.8°F). |
| Humidity requirements | Operating humidity: 10% to 90% RH (non-condensing) Storage humidity: 5% to 95% RH (non-condensing) |
Warranty
Public manufacturer information does not specify the warranty term applicable to our supply channel. The supply region, channel and actual warranty service are confirmed in the supply contract.
