Key Architecture Highlights
- Management Ports: 1 x RJ45 console port
- USB Interface: 1 x USB 2.0 port
- Packet forwarding rate: 72Mpps
Applications
- Corporate network
- Campus and office networks
Engineering Parameters
| Management Ports | 1 x RJ45 console port |
|---|---|
| USB Interface | 1 x USB 2.0 port |
| Packet forwarding rate | 72Mpps |
| Switching capacity | 96 Gbps |
| Processor | Two-core CPU, ARM Cortex™ A55, each core with the clock speed of 1.0GHz |
| Flash Storage | 512 MB |
| Memory | 1GB DDR4 |
| Device dimensions (Width × Depth × Height) | 150mm x 133mm x 86mm |
| Net weight | 1.49kg |
| Power supply Input | AC input: ● Rated voltage: 100V~240V AC, 50/60Hz ● Maximum voltage: 90V~264V AC, 50/60Hz ● Rated current: 0.6A HVDC input: ● Rated voltage: 240V DC ● Maximum voltage: 204V~288V DC ● Rated current: 0.3A |
| Maximum Power consumption | 110 V AC: 16.7W 220 V AC: 16.8W 240 V AC: 16.8W |
| Operating temperature | Operating temperature: (at an altitude below 1,800 m [5,905.51 ft.], with industrial optical transceivers installed) ● –40°C to +65°C (–40°F to +149°F) (installed in an enclosed cabinet) ● –40°C to +70°C (–40°F to +158°F) (installed in a ventilated cabinet with a minimum air velocity of 80 Line Feet Minute [LFM]) ● –40°C to +75°C (–40°F to +167°F) (installed in a fan-equipped cabinet with a minimum air velocity of 200 LFM) Note: At an altitude between 1,800 m (5,905.51 ft.) and 5,000 m (16,404.20 ft.), every time the altitude increases by 220 m (721.78 ft.), the maximum temperature decreases by 1°C (1.8°F). Storage temperature: –40°C to +85°C (–40℉ to +185℉) |
| Humidity requirements | Operating humidity: 5% to 95% RH, Non-condensing Storage humidity: 5% to 95% RH |
| Altitude range | Storage altitude: 0 m to 5,000 m (0 ft. to 16,404.20 ft.) Operating altitude: 0 m to 5,000 m (0 ft. to 16,404.20 ft.) |
Warranty
Public manufacturer information does not specify the warranty term applicable to our supply channel. The supply region, channel and actual warranty service are confirmed in the supply contract.
