Key Architecture Highlights
- Interface: 1 x 100/1000/2.5GBASE-T port 1 x 5GE SFP port, which is compatible with 1GE and 2.5GE transceivers 1 x RJ45 console port 1 x USB 2.0 port (Type A connector) 1 x Bluetooth 5.3
- Chassis dimensions: Main unit: 200 mm x 200 mm x 40 mm (7.87 in. x 7.87 in. x 1.57 in.) Shipping: 500 mm x 390 mm x 260 mm (19.69 in. x 15.35 in. x 10.24 in.)
- Weight: Main unit: 0.64 kg (1.41 lbs) Mounting bracket: 0.06 kg (0.13 lbs) Shipping: 12.18 kg (26.85 lbs)
Applications
- Business wireless coverage
- Campus and office networks
Engineering Parameters
| Wireless Capability | Wi-Fi 6 Wireless Capability: Four spatial streams ● Radio 1 --2.4 GHz: 2x2 uplink / downlink MU-MIMO, two spatial streams ● Radio 2 --5 GHz: 2x2 uplink / downlink MU-MIMO, two spatial streams Channels: ● Radio 1 --2.4 GHz: 20 MHz and 40 MHz ● Radio 2 --5 GHz: 20 MHz, 40 MHz, 80 MHz, and 160 MHz Combined peak data rate: 2.976 Gbps Wi-Fi 7 Wireless Capability: Four spatial streams ● Radio 1 --2.4 GHz: 2x2 uplink / downlink MU-MIMO, two spatial streams ● Radio 2 --5 GHz: 2x2 uplink / downlink MU-MIMO, two spatial streams Channels: ● Radio 1 --2.4 GHz: 20 MHz and 40 MHz ● Radio 2 --5 GHz: 20 MHz, 40 MHz, 80 MHz, and 160 MHz Combined peak data rate: 3.570 Gbps |
|---|---|
| Antenna | Wi-Fi ● 2.4 GHz: Two built-in omnidirectional smart antennas, with the peak antenna gain of 4.5 dBi ● 5 GHz: Two built-in omnidirectional smart antennas, with the peak antenna gain of 5.2 dBi Bluetooth ● One built-in omnidirectional antenna, with the peak antenna gain of 4.5 dBi |
| Interface | 1 x 100/1000/2.5GBASE-T port 1 x 5GE SFP port, which is compatible with 1GE and 2.5GE transceivers 1 x RJ45 console port 1 x USB 2.0 port (Type A connector) 1 x Bluetooth 5.3 |
| Chassis dimensions | Main unit: 200 mm x 200 mm x 40 mm (7.87 in. x 7.87 in. x 1.57 in.) Shipping: 500 mm x 390 mm x 260 mm (19.69 in. x 15.35 in. x 10.24 in.) |
| Weight | Main unit: 0.64 kg (1.41 lbs) Mounting bracket: 0.06 kg (0.13 lbs) Shipping: 12.18 kg (26.85 lbs) |
| Installation method | Ceiling/Wall-mount |
| Power input Specifications | The AP supports the following power supply modes: ● 48 V DC/0.54 A power input over the DC connector ● PoE/PoE+ input, in compliance with IEEE 802.3af/at Note: ● If both DC power and PoE are available, DC power is preferred. ● When 802.3af power supply is used, the AP starts up normally. In this case, the USB port is disabled, the maximum transmit power of radios is 19 dBm, and optical ports are not supported. |
| Maximum Power consumption | Maximum power consumption: 18.5 W ● DC power: 18.5 W, 2.4 GHz radio 2x2, 5 GHz radio 2x2, maximum radio power of 23 dBm, and USB port for external power supply ● 802.3at (PoE+): 18.5 W, 2.4 GHz radio 2x2, 5 GHz radio 2x2, maximum radio power of 23 dBm, and USB port for external power supply ● 802.3af (PoE): 12.95 W, 2.4 GHz radio 2x2, 5 GHz radio 2x2, maximum radio power of 19 dBm, and USB port disabled ● Idle mode: 5.5 W |
Warranty
Public manufacturer information does not specify the warranty term applicable to our supply channel. The supply region, channel and actual warranty service are confirmed in the supply contract.
