Key Architecture Highlights
- Interface: 1 x 10/100/1000/2.5GBASE-T port 4 x 10/100/1000BASE-T ports 1 x RJ45 console port (serial console port) 1 x USB 3.0 (Type A connector) 1 x Bluetooth 5.1
- Dimensions (Width × Height × Depth): Main unit: 86 mm x 160 mm x 35 mm (3.39 in. x 6.30 in. x 1.38 in.) Shipping:113 mm x 177.5 mm x 63 mm (4.45 in. x 6.99 in. x 2.48 in.)
- Weight: Main unit: 0.3 kg (0.66 lbs) Mounting bracket: 0.05 kg (0.11 lbs) Shipping:0.43 kg (0.95 lbs)
Applications
- Corporate network
- Campus and office networks
Engineering Parameters
| 802.11n Wireless Capability | 4 spatial streams; ● Radio 1 --2.4 GHz: 2x2 MIMO, two spatial streams; ● Radio 2 --5 GHz: 2x2 MIMO, two spatial streams; Channel:; ● Radio 1 --2.4 GHz: 20 MHz and 40 MHz; ● Radio 2 --5 GHz: 20 MHz and 40 MHz; Combined peak data rate: 600 Mbps; ● Radio 1 --2.4 GHz: 6.5 Mbps to 300 Mbps (MCS0 to MCS15); ● Radio 2 --5 GHz: 6.5 Mbps to 300 Mbps (MCS0 to MCS15) |
|---|---|
| 802.11ac Wireless Capability | 2 spatial streams; ● Radio 2 --5 GHz: 2x2 downlink MU-MIMO, two spatial streams; ● Channel:; ● Radio 2 --5 GHz: 20 MHz, 40 MHz, 80 MHz, and 160 MHz; Combined peak data rate: 1.733 Gbps; Radio 2 --5 GHz: 6.5 Mbps to 1.733 Gbps (MCS0 to MCS9) |
| 802.11ax Wireless Capability | 4 spatial streams; ● Radio 1 --2.4 GHz: 2x2 uplink/downlink MU-MIMO, two spatial streams; ● Radio 2 --5 GHz: 2x2 uplink/downlink MU-MIMO, two spatial streams; Channel:; ● Radio 1 --2.4 GHz: 20 MHz and 40 MHz; ● Radio 2 --5 GHz: 20 MHz, 40 MHz, 80 MHz, and 160 MHz; Combined peak data rate: 2.976 Gbps; ● Radio 1 --2.4 GHz: 7.3 Mbps to 0.574 Gbps (MCS0 to MCS11); ● Radio 2 --5 GHz: 7.3 Mbps to 2.402 Gbps (MCS0 to MCS11) |
| 802.11be Wireless Capability | 4 spatial streams; ● Radio 1 --2.4 GHz: 2x2 uplink/downlink MU-MIMO, two spatial streams; ● Radio 2 --5 GHz: 2x2 uplink/downlink MU-MIMO, two spatial streams; ● Channel:; ● Radio 1 --2.4 GHz: 20 MHz and 40 MHz; ● Radio 2 --5 GHz: 20 MHz, 40 MHz, 80 MHz, and 160 MHz; Combined peak data rate: 3.570 Gbps; ● Radio 1 --2.4 GHz: 7.3 Mbps to 0.688 Gbps (MCS0 to MCS13); ● Radio 2 --5 GHz: 7.3 Mbps to 2.882 Gbps (MCS0 to MCS13) |
| Antenna | Wi-Fi ● 2.4 GHz: Two built-in omnidirectional antennas, with the peak antenna gain of 3 dBi ● 5 GHz: Four built-in omnidirectional antennas, with the peak antenna gain of 3.8 dBi Bluetooth ● One built-in vertically polarized omnidirectional antenna, with the peak antenna gain of 4.3 dBi |
| Interface | 1 x 10/100/1000/2.5GBASE-T port 4 x 10/100/1000BASE-T ports 1 x RJ45 console port (serial console port) 1 x USB 3.0 (Type A connector) 1 x Bluetooth 5.1 |
| Dimensions (Width × Height × Depth) | Main unit: 86 mm x 160 mm x 35 mm (3.39 in. x 6.30 in. x 1.38 in.) Shipping:113 mm x 177.5 mm x 63 mm (4.45 in. x 6.99 in. x 2.48 in.) |
| Weight | Main unit: 0.3 kg (0.66 lbs) Mounting bracket: 0.05 kg (0.11 lbs) Shipping:0.43 kg (0.95 lbs) |
Warranty
Public manufacturer information does not specify the warranty term applicable to our supply channel. The supply region, channel and actual warranty service are confirmed in the supply contract.
