Key Architecture Highlights
- Chassis form factor: 2U
- Chassis dimensions: 438mm(17.2") Wx 87mm(3.4") Hx 764mm(30")D
- Processors and sockets: Supported processors: Single Intel® Xeon® 6700E-series, 6500P-series and 6700P-series processor, TDP up to 350W processor socket: 1) LGA4710 (Socket E2)
Applications
- Corporate data center computing
- Virtualization and cloud computing
Engineering Parameters
| Chassis form factor | 2U |
|---|---|
| Chassis dimensions | 438mm(17.2") Wx 87mm(3.4") Hx 764mm(30")D |
| Processors and sockets | Supported processors: Single Intel® Xeon® 6700E-series, 6500P-series and 6700P-series processor, TDP up to 350W processor socket: 1) LGA4710 (Socket E2) |
| Memory support | (16) DDR5 DIMM Slots, 8 channels(2DPC), RDIMM/RDIMM-3DS/MRDIMM; - Max. Frequency:; RDIMM: ; 6500P/6700P series: 6400 MT/s (1DPC), 6000 MT/s (2DPC); 6700E series: 6400 MT/s (1DPC), 5200 MT/s (2DPC); MRDIMM: 8000MT/s(only support 1DPC); - Max. Capacity per DIMM: 256GB(RDIMM), 64GB(MRDIMM); *MRDIMMs are only supported with Intel® Xeon® 6 P-core series processors |
| Drive bays | (8) Front hot-swap 2.5" U.2 PCIe 5.0 x4 NVMe drive bays |
| Internal Storage | (2) 2280/22110 PCIe 5.0 x2 NVMe M.2 ports |
| Expansion slots | (2) FHFL PCIe5 x16 double wide slots support max 400W PCIe card(one slot is only functional with R1S CPU ); (1) HHHL PCIe5 x16 single wide slot |
| Networking and interfaces | Network interfaces: (2) PCIe 5.0 x16 OCP3.0 slots (NCSI supported); * NCSI only one slot is functional at the same time; * OCP1 slot is only functional with R1S CPU Front interfaces: (8) Hot-swap 2.5" U. 2 drive bays; (2) USB 3.0 Type-A Ports; (1) System Power LED Button; (1) UID LED Button; (1) Reset Button; (4) Status LEDs: Fault / LAN / M.2 Rear interfaces: (1) 1000Base-T Dedicated Server Management Ports; (1) COM USB Type A port; (1) USB 2.0 Type-A Ports; (1) Mini Display port; (1) Power LED (Green) Button; (1) UID LED (Blue) Button; (1) Status LEDs: Green / Red |
| Security features | Chassis Intrusion; TPM2.0 module supported (optional); ASPEED AST1060 Hardware Root of Trust module supported (optional) |
| Server management | (1) 1000Base-T Dedicated Server Management Port; ASPEED AST2600 with AMI MegaRAC based firmware supporting IPMI 2.0 and DMTF Redfish API; Dual BIOS and dual BMC; eMMC for local BMC storage media |
| Supported operating systems | Windows 2025; Ubuntu 24.04; Redhat 9.0; Rocky 8.10; Rocky 9.7; Rocky 10.1 |
Warranty
Public manufacturer information does not specify the warranty term applicable to our supply channel. The supply region, channel and actual warranty service are confirmed in the supply contract.
