Key Architecture Highlights
- Memory: Memory - memory technology: Dual-channel DDR5 ((ECC/non-ECC) 5600MHz (ECC support & Frequency will depend on CPU Memory - memory capacity Up to 96GB Memory - memory slots:2 x 262-pin SO-DIMMs
- Show Output: Graphic - controller: Intel® UHD Graphics Graphic memory: Depends on CPU Graphic - Multi-screen support: 4 Independent displays Graphic - display interfaces: HDMI up to 4096 x 2304 @60Hz DP up to 4096 x 2304 @60Hz
- Wireless Network: 1 x Intel® I226LM 2.5GbE LAN (Support Intel® AMT) 3 x Intel® I226V 2.5GbE LAN
Applications
- The Edge of AI
- Local AI development
- Industrial intelligence
Engineering Parameters
| Processor And Calculator | System Processor - Processor: Intel ® 12th Gen IOTG Alder Lake-S Processor Core i9/i7/i5/i3, Pentium ®, Celeron ® Processor, Ma x. 65W Intel ® 13th Gen IOTG Raptor Lake-S Processor Core i9/i7/i5/i3, Ma x. 65W Intel ® 14th Gen IOTG Raptor Lake-S Refresh Processor Core i9/i7/i5/i3, Ma x. 65W Intel ® Core 200S series processors (Bartlett Lake S, Ma x 65W) Intel ® Core Processors Series 2 Bartlett Lake-S Core 7/5/3, Ma x 65W System Processor - Processor Frequency: P-Core 1.1 GHz ~ 5.5 GHz (Depends on CPU) E-Core 0.8 GHz ~ 4.0 GHz (Depends on CPU) System Processor - L2 Cache: 4M ~ 36M (Depends on CPU) System Processor - Processor Type: Socket (LGA1700) |
|---|---|
| Memory | Memory - memory technology: Dual-channel DDR5 ((ECC/non-ECC) 5600MHz (ECC support & Frequency will depend on CPU Memory - memory capacity Up to 96GB Memory - memory slots:2 x 262-pin SO-DIMMs |
| Show Output | Graphic - controller: Intel® UHD Graphics Graphic memory: Depends on CPU Graphic - Multi-screen support: 4 Independent displays Graphic - display interfaces: HDMI up to 4096 x 2304 @60Hz DP up to 4096 x 2304 @60Hz |
| Wireless Network | 1 x Intel® I226LM 2.5GbE LAN (Support Intel® AMT) 3 x Intel® I226V 2.5GbE LAN |
| External interfaces | I/O Interface - RJ-45 interface :4 I/O Interface - Audio interface :1 x Mic-in 1 x Line-out I/O Interface - USB interface :8 x USB 3.2 Gen 2 2 x USB 2.0 (internal) I/O Interface - Serial ports :4 x COM ports COM1 to 2: RS232/422/485, 0V/5V/12V COM3 to 4: RS-232, 0V I/O Interface - HDMI interface :2 I/O Interface - Display interface :2 |
| Expansion Interface | 1 x M.2 M key (PCIe Gen4 x4 NVMe & SATA 3.0), 2280 |
| Storage | 2 x 2.5" HDD/SSD |
| Power input | DC-In 12-48V Wide-Range Pluggable connectors with latch (V+, V-) |
| Environmental requirements | Environment - operating temperature:-10 ~ 40 °C w/ industrial DC power, Up to 65W CPU with Fan and Graphic Card Environment - operating humidity::10 ~ 90% , non-condensing Environment - storage Humidity:10 ~ 90%, non-condensing Environment - storage temperature:-20 ~ 80°C |
| Dimensions And Install | Physical Characteristics - device dimensions :285 x 217 x 431.1 mm Physical Characteristics - weight :11 kg Physical Characteristics - installation method: Wall mount |
Warranty
Public manufacturer information does not specify the warranty term applicable to our supply channel. The supply region, channel and actual warranty service are confirmed in the supply contract.
