Key Architecture Highlights
- Memory: Memory - memory technology: Dual-channel DDR5 (ECC/non-ECC) 5600MHz (ECC support & Frequency will depend on CPU) Memory - memory capacity Up to 64GB
- Show Output: Graphic - controller: Intel® UHD Graphics Graphic - graphical memory: Depends on the CPU
- Wireless Network: 1 x Intel® I226LM 2.5GbE LAN (Support Intel® AMT) 3 x Intel® I226V 2.5GbE LAN
Applications
- The Edge of AI
- Local AI development
- Industrial intelligence
Engineering Parameters
| Processor And Calculator | System Processor: Intel® 12th Gen IOTG Alder Lake-S Processor Core i9/i7/i5/i3, Pentium®, Celeron® Processor, Max. 35W Inte® 13th Gen IOTG Raptor Lake-S Processor Core i9/i7/i5/i3, Max. 35W Intel® 14th Gen IOTG Raptor Lake-S Refresh Processor Core i9/i7/i5/i3, Max. 35W System Processor - processor frequency: P-Core 1.1 GHz to 5.5 GHz (Depends on CPU) E-Core 0.8 GHz to 4.0 GHz (Depends on CPU) |
|---|---|
| Memory | Memory - memory technology: Dual-channel DDR5 (ECC/non-ECC) 5600MHz (ECC support & Frequency will depend on CPU) Memory - memory capacity Up to 64GB |
| Show Output | Graphic - controller: Intel® UHD Graphics Graphic - graphical memory: Depends on the CPU |
| Wireless Network | 1 x Intel® I226LM 2.5GbE LAN (Support Intel® AMT) 3 x Intel® I226V 2.5GbE LAN |
| External interfaces | I/O Interface - RJ-45 interface: 4 I/O Interface - Audio interface: 1 x Mic-in 1 x Line-out |
| Expansion Interface | 1 x M.2 M key (PCIe Gen4 x4 NVMe & SATA 3.0), 2280 1 x M.2 E key (PCIe Gen4 x1, USB2.0), 2230 1 x M.2 M key (PCIe Gen4 x4 NVMe & SATA 3.0), 2280 |
| Storage | 2 x 2.5" HDD/SSD 2 x 2.5" HDD/SSD (Customer-selected assembly — occupies 1 PCIe x8 slot) |
| Power input | DC-In 8-48V Wide-Range Pluggable connectors with latch (V+, V-) |
| Environmental requirements | Environment - operating temperature:-10 ~ 50°C w/ industrial DC power Up to 35W CPU Note: Thermal w/ Airflow: 0.7m/s Environment - operating humidity::10 ~ 90% , non-condensing |
| Dimensions And Install | Physical Characteristics - device dimensions :178 x 242 x 217 mm Physical Characteristics - device dimensions :142 x 240 x 217 mm Physical Characteristics - device dimensions :123 x 240 x 217 mm Physical Characteristics - device dimensions :127 x 240 x 217 mm Physical Characteristics - weight: 5.0 kg Physical Characteristics - weight :4.4 kg Physical Characteristics - weight :4.3 kg |
| Software Platform | Windows 10 IoT Enterprise 2021 LTSC (64-bit, 21H2) Windows 11 IoT Enterprise 24H2 LTSC (64-bit) Linux (Support by request) |
Warranty
Public manufacturer information does not specify the warranty term applicable to our supply channel. The supply region, channel and actual warranty service are confirmed in the supply contract.
