Key Architecture Highlights
- Processor And Calculator: System processor - processor :20 core ARM, 10 Cortex-X925 + 10 Cortex-A725 ARM system processor - Tensor compute performance :1 petaFLOP Al Performance (FP4, Sparse)
- Show Output: Graphic - controller: Nvidia® GB10 Graphic memory: Share 128GB unified Memory Graphic - Multi-screen support: 4 independent displays Graphic - display interfaces: HDMI 2.1, 4x DP1.4a via USB-C
- Wireless Network: 1 x 10GbE
Applications
- The Edge of AI
- Local AI development
- Industrial intelligence
Engineering Parameters
| Processor And Calculator | System processor - processor :20 core ARM, 10 Cortex-X925 + 10 Cortex-A725 ARM system processor - Tensor compute performance :1 petaFLOP Al Performance (FP4, Sparse) |
|---|---|
| Memory | Memory - memory technology: LPDDR5x Memory - memory capacity up to 128 GB Memory - memory slots: onboard Specification - system memory :64 GB LPDDR5x, unified system memory Specification - system memory :128 GB LPDDR5x, unified system memory |
| Show Output | Graphic - controller: Nvidia® GB10 Graphic memory: Share 128GB unified Memory Graphic - Multi-screen support: 4 independent displays Graphic - display interfaces: HDMI 2.1, 4x DP1.4a via USB-C |
| Wireless Network | 1 x 10GbE |
| External interfaces | I / O Interface - RJ-45 Interface: 1 I / O Interface - Audio Interface: HDMI Multichannel Audio output I / O Interface - USB Interface: 4x USB 3.2 Type C (up to 20Gb/s) I / O Interface - USB Interface: 4 x USB 3.2 Type-C I / O Interface - HDMI Interface: 1 |
| Expansion Interface | 1x M.2 M Key 1TB/4TB SSD with self-encryption |
| Power input | ~240W USB-C with external power adapter |
| Environmental requirements | Environment - operating temperature: 0 ~ 35°C Environment - operating humidity: 10 ~ 90%, non-condensing Environment - storage Humidity: 10 ~ 90%, non-condensing Environment - storage temperature: 0 ~ 60°C |
| Dimensions And Install | Physical Characteristics - Device dimensions: 151 x 151 x 52 mm Physical Characteristics - Weight: 1.2 kg |
| Storage | 1 or 2 TB NVME.M2 with optional self-encryption 1, 2 or 4 TB NVME.M2 with self-encryption |
| Software Platform | NVIDIA DGX™ OS |
