Key Architecture Highlights
- Supported processors: Supported processor number: 2 supported processors: two 4th generation Intel® Xeon® expandable processors, up to 32 cores per processor or; two 5th generation Intel® Xeon® expandable processors, up to 16 cores per processor
- Memory slots / capacity: DIMM slot Number: 16 DDR5 DIMM slots supports up to memory: maximum 2TB of memory type: DDR5 registered ECC RDIMM
- Memory speed: The maximum is 5200MT/s
Applications
- Industrial automation
- Video analysis
- Data analytics for the sale of terminals
- AI reasoning
- Aggregation of edge devices data
Engineering Parameters
| Supported processors | Supported processor number: 2 supported processors: two 4th generation Intel® Xeon® expandable processors, up to 32 cores per processor or; two 5th generation Intel® Xeon® expandable processors, up to 16 cores per processor |
|---|---|
| Memory slots / capacity | DIMM slot Number: 16 DDR5 DIMM slots supports up to memory: maximum 2TB of memory type: DDR5 registered ECC RDIMM |
| Memory speed | The maximum is 5200MT/s |
| GPU / accelerator support | maximum four 75 W single-width full-height/half-length + one 75 W low-profile, or maximum two 350 W double-width full-height/full-length |
| Drive bays (Major programme) | Drive bays (pre-set): maximum 4 x 2.5 inches SAS/SATA/NVMe SSD drives, 61.44 TB maximum drive bays (pre-set): maximum 8 x E3.S NVMe direct drives, 51.2 TB maximum |
| Storage controller ／ RAID | storage controller: internal controller: PERC H965i, PERC H755, PERC;H355, HBA355i; software RAID: S160; internal boot: Boot Optimized Storage Subsystem (BOSS-N1):; HWRAID 1, 2 x M.2 NVMe SSDs (turn switch) or internal; USB module |
| PCIe Expansion | 2 CPU configuration: maximum 5 PCIe slots (4 x 16 Gen4/5, 1 x 16 LP Gen4) |
| Network interfaces ／ Expansion | The following table shows the number of devices that can be used to connect a network adapter: 2 x 1 GbE LOM network adapter expansion: 1 x OCP card 3.0 (optional) |
| External interfaces | port configuration (after maintenance): front-end ports: 1 x iDRAC Direct (Micro-AB USB) port, 1 x USB 2.0; internal ports:; 1 x USB 3.0 (optional); back-end ports:; 1 x USB 2.0, 1 x iDRAC dedicated port, 1 x USB 3.0,; 1 x Serial port (optional on slot 5), 1 x VGA port (pre-maintenance): front-end ports: 1 x USB 2.0, 1 x iDRAC dedicated port, 1 x USB 3.0, 1 x Serial port; option on slot 5), 1 x VGA, 1 x iDRAC Direct (Micro-AB USB) port; internal ports: 1 x USB 3.0 (optional); back-end ports: NA |
| Power supply options | 1800 W aluminium grade 200 ton 240 VAC or 240 HVDC 1400 W aluminium grade 100 ton 240 VAC or 240 HVDC 1400 W aluminium grade 277 VAC or 336 VDC 1100 W aluminium grade 100 ton 240 VAC or 240 HVDC, hot-swappable redundant |
Warranty
Implementation of Dell's official limited hardware warranty policy; specific deadlines, service levels, regional availability and transfer eligibility, as determined by service label queries and supply terms.
