Key Architecture Highlights
- Supported processors: Number of processors supported: 2 supported processor schemes: two 5th generation Intel Xeon expandable processors, up to 64 cores per processor; two 4th generation Intel Xeon expandable processors, up to 56 cores per processor
- Memory slots / capacity: DIMM slot number: 32 DDR5 DIMM slots supports up to memory: maximum 4TB memory type: DDR5 registered ECC RDIMM
- Memory speed: Maximum speed 5600 MT/s for the 5th generation Intel Xeon Scalable processor Maximum speed 4800 MT/s for the 4th generation Intel Xeon Scalable processor
Applications
- Artificial intelligence
- Machine learning training
- Deep learning training
- High-performance computing (HPC)
Engineering Parameters
| Supported processors | Number of processors supported: 2 supported processor schemes: two 5th generation Intel Xeon expandable processors, up to 64 cores per processor; two 4th generation Intel Xeon expandable processors, up to 56 cores per processor |
|---|---|
| Memory slots / capacity | DIMM slot number: 32 DDR5 DIMM slots supports up to memory: maximum 4TB memory type: DDR5 registered ECC RDIMM |
| Memory speed | Maximum speed 5600 MT/s for the 5th generation Intel Xeon Scalable processor Maximum speed 4800 MT/s for the 4th generation Intel Xeon Scalable processor |
| GPU / accelerator support | 8 NVIDIA HGX H100 80GB 700W SXM5 GPU, Full interconnectivity NVIDIA NVLink Technology Or 8 NVIDIA HGX H200 141GB 700W SXM5 GPU, Full interconnectivity NVIDIA NVLink Technology Or 8 NVIDIA HGX H20 96GB 500W SXM5 GPU, Full interconnectivity NVIDIA NVLink Technology Or 8 AMD Instinct MI300X 192GB 750W OAM Accelerator, Adopt AMD Infinity Fabric connectivity Or 8 Intel Gaudi 3 128GB 900W OAM Accelerator, Adopt Internal RoCE Ports For Ethernet Connection |
| Drive bays (Major programme) | Drive bays (pre-set): Maximum 8 x 2.5 inches NVMe/SAS/SATA SSD drives Maximum 122.88 TB drive bays (pre-set): Maximum 16 x E3.S NVMe direct drives Maximum 122.88 TB drive bays Configuration restrictions: Note: Only 8 x 2.5 inches NVMe SSD drives are supported with Intel Gaudi3. |
| Storage controller ／ RAID | Storage controller: Internal Controller (RAID): PERC H965i (Intel Gaudi 3 Configuration Not supported); Internal boot: Boot Optimized Storage Subsystem (NVMe BOSS-N1): HWRAID 1, 2 x M.2 SSDs; Software RAID: S160 |
| PCIe Expansion | Maximum 10 x 16 Gen5 (x16 PCIe) full-height, half-length (8 PCIe slots with Intel Gaudi 3) |
| Network interfaces ／ Expansion | The network adapter is board-loaded: 2 x 1 GbE OSFP network ports 6 x 800 Gb (for Intel Gaudi 3 configuration only) network adapter expansion :1 x OCP 3.0 (x8 PCIe lanes). |
| External interfaces | Port configuration: front-end ports; 1 x iDRAC Direct (Micro-AB USB) port; 1 x USB 2.0; 1 x VGA port configuration: back-end ports; 1 x USB 2.0; 1 x USB 3.0; 1 x VGA; 1 x RJ45 iDRAC9 ethernet port |
| Power supply options |
Warranty
Implementation of Dell's official limited hardware warranty policy; specific deadlines, service levels, regional availability and transfer eligibility, as determined by service label queries and supply terms.
