Key Architecture Highlights
- Supported processors: Supports Processor Count: Up to 2 Processors; Supported processors Programme: Two. Processors Generation 5 Generation AMD EPYC 9005 Series Processor, Up to 192 _Other Organiser Processors Processor
- Memory slots / capacity: DIMM slot Number: 24 DDR5 DIMM slots supports up to memory: up to 6TB( Current installation manual; earlier specification book lists 3TB) memory type: DDR5 registered RDIMM; not supported UDIMM
- Memory speed: Up to 6400MT/s (1DPC)
Applications
- AI reasoning
- AI modeling is fine-tuned
- High-performance computing
Engineering Parameters
| Supported processors | Supports Processor Count: Up to 2 Processors Supported processors Programme: Two. Processors Generation 5 Generation AMD EPYC 9005 Series Processor, Up to 192 _Other Organiser Processors Processor |
|---|---|
| Memory slots / capacity | DIMM slot Number: 24 DDR5 DIMM slots supports up to memory: up to 6TB( Current installation manual; earlier specification book lists 3TB) memory type: DDR5 registered RDIMM; not supported UDIMM |
| Memory speed | Up to 6400MT/s (1DPC) |
| GPU / accelerator support | 8x PCIe Gen 5 x 16 double width full length maximum 600W or 16x PCIe Gen 5 x 16 single width full length maximum 75W |
| Drive bays (Major programme) | Drive bays (pre-set): up to 8 x EDSFF E3.S Gen5 NVMe (SSD) and up to 122.88 TB |
| Storage controller ／ RAID | Storage controller: Internal boot: Boot Optimized Storage Subsystem (BOSS-N1 DC-MHS): HWRAID 1, 2 x M.2 NVMe SSDs or USB |
| PCIe Expansion | Maximum 8 PCIe Gen5 x16 single width all-high half-length cards, each maximum 150W |
| External interfaces | Port configuration: Prefix Ports:; 1 x USB 2.0 Type-A (Optional); 1 x Mini-Display port (Optional); 1 x USB 2.0 Type-C dual mode (Host / iDRAC Direct port) Port configuration: Back Ports on DC-SCM:; 1 x Dedicated iDRAC / BMC Direct Ethernet Ports; 2 x USB 3.1 Type A port; 1 x VGA Port configuration: Internal Ports:; 1 x USB 3.1 Type-A |
| Power supply options | 3200W Aluminum Grade 200-240 V AC or 240 V DC, hot-swappable redundant Multi capacity for 3200W PSU:3200W for 220.1-240 V AC or 2900W for 200-220 V AC |
| Cooling support | cooling method: wind-cooled fan configuration: maximum four sets of high performance platinum grade fans (HPR) installed in mid tray; maximum twelve high performance platinum grade fans (HPR) installed on the front of the system; All are hot-swappable fans |
| Management features | iDRAC10 iDRAC Direct iDRAC RESTful API with Redfish iDRAC Service Module (iSM); RACADM CLI |
| Hardware security support |
Warranty
Implementation of Dell's official limited hardware warranty policy; specific deadlines, service levels, regional availability and transfer eligibility, as determined by service label queries and supply terms.
