Key Architecture Highlights
- Supported processors: Number of supported processors: maximum 2 supported processor schemes: maximum two 4 generation Intel® Xeon expandable processors, maximum 32 cores per processor; maximum two 5 generation Intel® Xeon expandable processors, maximum 28 cores per processor
- Memory slots / capacity: DIMM slot Number: 16 DDR5 DIMM slots supports up to memory: up to 1.5TB of memory type: DDR5 registered ECC RDIMM
- Memory speed: Rate Up to 4800 MT/s For No. 4 Generation Intel ® Xeon Scalable Processor; Rate Up to 5200 MT/s For No. 5 Generation Intel ® Xeon Scalable Processor
Applications
- Corporate IT
- Database and data analysis
- Virtualization
- AI/machine learning reasoning
- Remote and branch offices
Engineering Parameters
| Supported processors | Number of supported processors: maximum 2 supported processor schemes: maximum two 4 generation Intel® Xeon expandable processors, maximum 32 cores per processor; maximum two 5 generation Intel® Xeon expandable processors, maximum 28 cores per processor |
|---|---|
| Memory slots / capacity | DIMM slot Number: 16 DDR5 DIMM slots supports up to memory: up to 1.5TB of memory type: DDR5 registered ECC RDIMM |
| Memory speed | Rate Up to 4800 MT/s For No. 4 Generation Intel ® Xeon Scalable Processor Rate Up to 5200 MT/s For No. 5 Generation Intel ® Xeon Scalable Processor |
| GPU / accelerator support | Maximum 2 x 300 W double width or 6 x 75 W single width |
| Drive bays (Major programme) | drive bays (pre-set): up to 12 x 3.5 inches SAS/SATA HDD drives, up to 180 TB drive bays (pre-set): up to 8 x 3.5 inches SAS/SATA HDD drives, up to 120 TB drive bays (pre-set): up to 8 x 3.5 inches SAS/SATA HDD + 8 x 2.5 inches NVMe SSD drives, up to 240 TB drive bays (pre-set): up to 8 x 2.5 inches SAS/SATA HDD drives, up to 120 TB |
| Storage controller ／ RAID | Internal PERC: fPERC H965i, fPERC H755N, fPERC H755, fPERC H355, fPERC HBA355i, HBA465i fPERC; internal booting: Boot Optimized Storage Subsystem (BOSS-N1): HWRAID 2 x M.2 NVMe SSD drives, or USB; external HBA (non-RAID): PERC HBA355e; software RAID: S160 (for NVMe drives only) |
| PCIe Expansion | Maximum six PCIe slots: Slot 1: x16 Gen5 full height, full length Slot 2: x16 Gen5 full height, full length |
| Network interfaces ／ Expansion | Board Network adapter: 2 x 1GbE LOM on Planar Network adapter Expansion: 1 x OCP x8 card 3.0; Annotations: The system allows both LOM on planar And OCP card to be installed on the system. |
| External interfaces | Port configuration: front-end ports; 1 x USB 2.0; 1 x USB 3.0; 1 x iDRAC Direct (Micro-AB USB) port configuration: back-end ports; 1 x USB 2.0; 1 x USB 3.0; 1 x Serial port (optional); 1 x Dedicated iDRAC (RJ45) port; 1 x VGA port; 2 x Ethernet ports s port configuration: internal ports; 1 x USB 3.0 (optional) |
| Power supply options | 600 W of aluminum grade 100-240 VAC/240 VDC 700 W of aluminum grade 200-240 VAC/240 VDC 800 W of aluminum grade 100-240 VAC/240 VDC 1100 W of aluminum grade 100-240 VAC/240 VDC |
Warranty
Implementation of Dell's official limited hardware warranty policy; specific deadlines, service levels, regional availability and transfer eligibility, as determined by service label queries and supply terms.
