Key Architecture Highlights
- Supported processors: Number of processors supported: 2 supported processor options: two Intel Xeon 6 Processors, 144 E-core or 86 P-core per processor
- Memory slots / capacity: DIMM slot number: 32 DDR5 DIMM slots supports up to memory: maximum 8TB memory type: DDR5 registered ECC RDIMM
- Memory speed: Maximum of 6400MT/s
Applications
- High-performance computing (HPC)
- Virtualization
- AI reasoning
- Cloud native applications
- Super-massive computing
- The horizontal expansion database
Engineering Parameters
| Supported processors | Number of processors supported: 2 supported processor options: two Intel Xeon 6 Processors, 144 E-core or 86 P-core per processor |
|---|---|
| Memory slots / capacity | DIMM slot number: 32 DDR5 DIMM slots supports up to memory: maximum 8TB memory type: DDR5 registered ECC RDIMM |
| Memory speed | Maximum of 6400MT/s |
| GPU / accelerator support | Maximum length 6 x 75 W full-length or maximum length 2 x 450 W double width |
| Drive bays (Major programme) | Drive bays: without backrest configuration drive bays (front): maximum 8 x EDSFF E3.S Gen5 NVMe up to 491.52 TB and also provide front-end I/O configuration drive bays (front): maximum 16 x EDSFF E3.S Gen5 NVMe up to 983.04 TB and also provide front-end I/O configuration drive bays (front): maximum 32 x EDSFF E3.S Gen5 NVMe up to 1966.08 TB |
| Storage controller ／ RAID | The storage controller: internal boot: Boot Optimized Storage Subsystem (BOSS-N1 DC-MHS): HWRAID 1,; 2 x M.2 NVMe SSDs or M.2 Interposer board (DC-MHS): 2 x M.2 NVMe SSDs or USB; internal controller: Front PERC H965i, Front PERC H975i, Front PERC H365i |
| PCIe Expansion | Upto two PCIe slots (x16 connectors) Slot 31 1 x 16 Gen5 Full length - half length or full length on front Riser Slot 36 1 x 16 Gen5 Full length - half length on front Riser |
| Network interfaces ／ Expansion | Network adapter expansion: OCP NIC card 3.0: Two slots on the front or two slots on the back |
| External interfaces | Port configuration: Prefix Ports:; 1 x USB 2.0 Type C port; 1 x USB 2.0 Type A port (Optional); 1 x Mini-Display Ports (Optional); 1 x DB9 Serial (with front I / O configuration); 1 x Dedicated ethernet port for iDRAC management Port configuration: Back Ports:; 1 x Dedicated ethernet port for iDRAC management; 1 x VGA; 2 x USB 3.1 Type A ports Port configuration: Internal Ports:; 1 x USB 3.1 Type A port |
| Power supply options | 800 W aluminium grade 100 ton 240 VAC or 240 VDC 1100 W aluminium grade 100 ton 240 VAC or 240 VDC 1500 W aluminium grade 100 ton 240 VAC or 240 VDC 1100 W aluminium grade 100 ton 240 VAC or 240 VDC |
Warranty
Implementation of Dell's official limited hardware warranty policy; specific deadlines, service levels, regional availability and transfer eligibility, as determined by service label queries and supply terms.
