Key Architecture Highlights
- Supported processors: Number of supported processors: maximum 2 supported processor schemes: maximum two AMD EPYC 4th generation 9004 Series, maximum 128 cores per processor
- Memory slots / capacity: DIMM slot number: 24 DDR5 DIMM slots supports up to memory: maximum 6TB memory type: DDR5 registered ECC RDIMM
- Memory speed: Maximum of 4800MT/s
Applications
- High-performance computing (HPC)
- The video is a virtual desktop (VDI)
- Virtualization
- Analysis of data
Engineering Parameters
| Supported processors | Number of supported processors: maximum 2 supported processor schemes: maximum two AMD EPYC 4th generation 9004 Series, maximum 128 cores per processor |
|---|---|
| Memory slots / capacity | DIMM slot number: 24 DDR5 DIMM slots supports up to memory: maximum 6TB memory type: DDR5 registered ECC RDIMM |
| Memory speed | Maximum of 4800MT/s |
| GPU / accelerator support | Maximum 2 x 300 W double width or 6 x 75 W single width |
| Drive bays (Major programme) | Drive bays (pre-set): maximum 8 x 3.5 inches SAS/SATA (HDD/SSD) maximum 160 TB drive bays (pre-set): maximum 12 x 3.5 inches SAS/SATA (HDD/SSD) maximum 240 TB drive bays (pre-set): maximum 8 x 2.5 inches SAS/SATA/NVMe (HDD/SSD) maximum 122.88 TB drive bays (pre-set): maximum 16 x 2.5 inches SAS/SATA/NVMe (HDD/SSD) maximum 245.76 TB |
| Storage controller ／ RAID | storage controller: internal controller (RAID): PERC H965i, PERC H755, PERC H755N, PERC H355, HBA355i; internal boot: Boot Optimized Storage Subsystem (BOSS-N1): HWRAID 2 x M.2 NVMe SSDs or USB; external HBA (non-RAID): HBA355e; software RAID: S160 |
| PCIe Expansion | Maximum eight PCIe slots: Slot 1: 1 x 8 Gen5 or 1 x 8 Gen4 Full length, Half-length Slot 2: 1 x 8/1 x 16 Gen5 or 1 x 8 Gen4 Full length, Half-length or 1 x 16 Gen5 Full Length |
| Network interfaces ／ Expansion | Board-loaded network adapter :2 x 1GbE LOM card (optional) network adapter expansion :1 x OCP card 3.0 (optional); Note: The system allows either a LOM card or an OCP card or both to be installed in the system. |
| External interfaces | port configuration: front-end ports; 1 x iDRAC Direct (Micro-AB USB) port; 1 x USB 2.0; 1 x VGA port configuration: back-end ports; 1 x Dedicated iDRAC ethernet port; 1 x USB 2.0; 1 x USB 3.0; 1 x Serial (optional); 1 x VGA (optional for direct liquid cold configuration) port configuration: internal ports; 1 x USB 3.0 (optional) |
| Power supply options | 3200 W of alloy steel grade 277 VAC or 336 VDC, hot-swappable redundant 2800 W of alloy steel grade 200 tonne 240 VAC or 240 HVDC, hot-swappable redundant 2400 W of alloy steel grade 100 tonne 240 VAC or 240 HVDC, hot-swappable redundant 1800 W of alloy steel grade 200 tonne 240 VAC or 240 HVDC, hot-swappable redundant |
Warranty
Implementation of Dell's official limited hardware warranty policy; specific deadlines, service levels, regional availability and transfer eligibility, as determined by service label queries and supply terms.
