Key Architecture Highlights
- Supported processors: Supports Processor Count: Up to 1 Processors; Supported processors Programme: One. Processors Generation 4 Generation AMD EPYC 9004 Series Processor, Up to 128 _Other Organiser Processors Processor
- Memory slots / capacity: DIMM slot number: 12 DDR5 DIMM slots supports up to memory: maximum 3TB memory type: DDR5 registered ECC RDIMM
- Memory speed: Maximum of 4800MT/s
Applications
- Software Defined Storage (SDS)
- Virtualization
- Analysis of data
Engineering Parameters
| Supported processors | Supports Processor Count: Up to 1 Processors Supported processors Programme: One. Processors Generation 4 Generation AMD EPYC 9004 Series Processor, Up to 128 _Other Organiser Processors Processor |
|---|---|
| Memory slots / capacity | DIMM slot number: 12 DDR5 DIMM slots supports up to memory: maximum 3TB memory type: DDR5 registered ECC RDIMM |
| Memory speed | Maximum of 4800MT/s |
| GPU / accelerator support | Maximum 3 x 300 W double width or 6 x 75 W single width |
| Drive bays (Major programme) | Drive bays (pre-set): maximum 8 x 3.5 inches SAS/SATA (HDD/SSD) maximum 160 TB drive bays (pre-set): maximum 12 x 3.5 inches SAS/SATA (HDD/SSD) maximum 240 TB drive bays (pre-set): maximum 8 x 2.5 inches SAS/SATA/NVMe (HDD/SSD) maximum 122.88 TB drive bays (pre-set): maximum 16 x 2.5 inches SAS/SATA/NVMe (HDD/SSD) maximum 245.76 TB |
| Storage controller ／ RAID | storage controller: internal controller: PERC H965i, PERC H755, PERC H755N, PERC H355, HBA355i; internal booting: Boot Optimized Storage Subsystem (BOSS-N1): HWRAID 2 x M.2 NVMe SSDs or USB; external HBA (non-RAID): HBA355e; software RAID: S160 |
| PCIe Expansion | Maximum eight PCIe slots: Slot 1: 1 x 8 Gen5 Full length, Half length Slot 2: 1 x 8/1 x 16 Gen5 Full length, Half length or 1 x 16 Gen5 Full length, Full length |
| Network interfaces ／ Expansion | Board Network adapter: 2 x 1 GbE LOM card (Optional) Network adapter Expansion: 1 x OCP card 3.0 (Optional); Annotations: The system allows either LOM card Or an OCP card Or both to be installed in the system. |
| External interfaces | port configuration: front-end ports; 1 x iDRAC Direct (Micro-AB USB) port; 1 x USB 2.0; 1 x VGA port configuration: back-end ports; 1 x Dedicated iDRAC Ethernet ports; 1 x USB 2.0; 1 x USB 3.0; 1 x VGA; 1 x Serial (optional); 1 x VGA (optional for direct liquid cold configuration) port configuration: internal ports; 1 x USB 3.0 (optional) |
| Power supply options | 2400 W aluminum grade 100 ton 240 VAC or 240 HVDC, hot-swappable redundant 1800 W aluminum grade 200 ton 240 VAC or 240 HVDC, hot-swappable redundant 1400 W aluminum grade 100 ton 240 VAC or 240 HVDC, hot-swappable redundant 1400 W aluminum grade 277 VAC or 336 HVDC, hot-swappable redundant |
Warranty
Implementation of Dell's official limited hardware warranty policy; specific deadlines, service levels, regional availability and transfer eligibility, as determined by service label queries and supply terms.
