Key Architecture Highlights
- Supported processors: Supports Processor Count: Up to 2 Processors; Supported processors Programme: Up to Two. Processors Generation 4 Generation Intel Xeon Yeah. Expansion Or Intel Xeon Ma x Processor,, Up to 56 cores And Optional Intel ® QuickAssist; Technology.; Up to Two. Processors Generation 5 Generation Intel Xeon Yeah. Expansion Processor, Up to 64 Nuclear.
- Memory slots / capacity: DIMM slot number: 32 DDR5 DIMM slots supports up to memory: maximum 8TB memory type: DDR5 registered ECC RDIMM
- Memory speed: Maximum speed 4800 MT/s for the 4th generation Intel Xeon Scalable or Intel Xeon Max processor Maximum speed 5600 MT/s for the 5th generation Intel Xeon Scalable processor
Applications
- High-density virtualization
- Database analysis
Engineering Parameters
| Supported processors | Supports Processor Count: Up to 2 Processors Supported processors Programme: Up to Two. Processors Generation 4 Generation Intel Xeon Yeah. Expansion Or Intel Xeon Ma x Processor,, Up to 56 cores And Optional Intel ® QuickAssist; Technology.; Up to Two. Processors Generation 5 Generation Intel Xeon Yeah. Expansion Processor, Up to 64 Nuclear. |
|---|---|
| Memory slots / capacity | DIMM slot number: 32 DDR5 DIMM slots supports up to memory: maximum 8TB memory type: DDR5 registered ECC RDIMM |
| Memory speed | Maximum speed 4800 MT/s for the 4th generation Intel Xeon Scalable or Intel Xeon Max processor Maximum speed 5600 MT/s for the 5th generation Intel Xeon Scalable processor |
| GPU / accelerator support | Maximum single width of 3 x 75 W |
| Drive bays (Major programme) | Drive bays (pre-set): up to 10 x 2.5 inches, SAS/SATA/NVMe (HDD/SSD) up to 153.6 TB drive bays (pre-set): up to 8 x 2.5 inches, SAS/SATA/NVMe, (HDD/SSD) up to 122.88 TB drive bays (pre-set): up to 14 x EDSFF E3.S Gen5 NVMe (SSD) up to 179.2 TB drive bays (pre-set): up to 16 x EDSFF E3.S Gen5 NVMe (SSD) up to 204.8 TB |
| Storage controller ／ RAID | storage controller: internal controller (RAID): PERC H965i, PERC H755, PERC H755N, PERC H355i; external controller: PERC H965e; internal bootable: Boot Optimized Storage Subsystem (BOSS-N1): HWRAID 2 x M.2 NVMe SSD drives, or USB; SAS HBAs (non-RAID): HBA355e, HBA355i, HBA465i; software RAID: S160 |
| PCIe Expansion | Maximum three PCIe slots: Slot 1 : 1 x 16 Gen5 full height, 3/4 length, half length or 1 x 8 / 1 x 16 Gen 5 or 1 x 16 Gen 4 half high, half length Slot 2 : 1 x 16 Gen5 full height, 3/4 length, half length or 1 x 16 Gen 5 or 1 x 16 Gen 4 half high, half length |
| Network interfaces ／ Expansion | Network adapter: 2 x 1 GbE LOM card (optional) network adapter expansion :1 x OCP card 3.0 (optional); Note: The system allows either LOM card or an OCP card or both to be installed in the system; 1 x Managemnet Interface Card (MIC) to support Dell Data Processing Unit (DPU card) (optional); Note: The system allows either LOM card or MIC card to be installed in the system. |
| External interfaces | port configuration: front-end ports; 1 x iDRAC Direct (Micro-AB USB) port; 1 x USB 2.0; 1 x VGA port configuration: back-end ports; 1 x Dedicated iDRAC Ethernet ports; 1 x USB 2.0; 1 x USB 3.0; 1 x Serial (optional); 1 x VGA (optional for direct liquid cold configuration) l port configuration: internal ports; 1 x USB 3.0 (optional) |
Warranty
Implementation of Dell's official limited hardware warranty policy; specific deadlines, service levels, regional availability and transfer eligibility, as determined by service label queries and supply terms.
