Key Architecture Highlights
- Port configuration: Maximum number of unified ports: 16 (unified ports 1-16) Maximum number of 1-Gbps Ethernet ports: 4 (ports 45-48)
- System memory ／ Storage: Ports / power input / software - system memory: 64 GB
- Management interface: L1, L2, and RJ-45 ports
Applications
- Data center connected
- server network access
Engineering Parameters
| Port configuration | Maximum number of unified ports: 16 (unified ports 1-16) Maximum number of 1-Gbps Ethernet ports: 4 (ports 45-48) |
|---|---|
| System memory ／ Storage | Ports / power input / software - system memory: 64 GB |
| Management interface | L1, L2, and RJ-45 ports |
| The whole plane. Power consumption | Typical operating power: 260W ports / power input / software - Maximum overall power consumption (AC): 650W |
| Cooling | Ports / power input / software - fan :4 ports / power input / software - Airflow direction: Standard airflow (PSU/fan-side) to back (port-side exhaust) |
| Installation form factor | 1RU |
| Dimensions | 1.72 in. x 17.3 in x 22.5 in (4.4 cm x 43.9 cm x 57.1 cm) |
| Reference weight | 22.24 lb (10.10 kg), with fans |
| Operating temperature | 32 to 104°F (0 to 40°C) |
| Operating humidity | 5 to 95% |
Warranty
The manufacturer's hardware warranty, software and subscription services must be confirmed separately; the specific timeframe, region, replacement method and eligibility are based on the manufacturer's terms, serial numbers and actual supply contracts, and the company's service offerings have not yet been confirmed.
