Key Architecture Highlights
- Data Interface: 8x 1000BASE-T
- Firewall throughput: FTD - Firewall + AVC throughput (1024B): 9.0 Gbps FTD - Firewall + AVC + IPS throughput (1024B): 9.0 Gbps ASA - State detection of firewall throughput [2]:15 Gbps(1500B UDP) ASA - State detection of firewall throughput (multiprotocol)[3]:12 Gbps
- TLS Decrypt Performance: FTD - TLS decryption[1]: 1.5 Gbps
Applications
- Border security for businesses
- Security of the Branch
- VPN access
Engineering Parameters
| Data Interface | 8x 1000BASE-T |
|---|---|
| Firewall throughput | FTD - Firewall + AVC throughput (1024B): 9.0 Gbps FTD - Firewall + AVC + IPS throughput (1024B): 9.0 Gbps ASA - State detection of firewall throughput [2]:15 Gbps(1500B UDP) ASA - State detection of firewall throughput (multiprotocol)[3]:12 Gbps |
| TLS Decrypt Performance | FTD - TLS decryption[1]: 1.5 Gbps |
| IPsec VPN Throughput | FTD - IPsec VPN Throughput (1024B TCP w / Fastpath): 10 Gbps ASA - IPsec VPN Throughput (450B UDP L2L test): 12 Gbps |
| Concurrent connections | FTD - Opening the largest concurrent session of AVC: 300K ASA - Firewall concurrent connections:300K |
| New connections per second | FTD - Opening new connections per second: 50K ASA - new connections per second:250K |
| VPN Yeah. Including End | The FTD - VPN peer limit is 300 ASA - VPN peer limit is 300. |
| Input voltage | 100-240V AC |
| Installation form factor | Desktop/ Compact |
| Dimensions | 1.11” x 10.8” x 6.8”; 2.82 x 27.43 x 17.22 cm |
| Reference weight | 3.09 lb (1.40 kg) |
| Operating temperature | 32 to 104°F (0 to 40°C) |
| Operating humidity | 5 to 85% (non-condensing) |
Warranty
The manufacturer's hardware warranty, software and subscription services must be confirmed separately; the specific timeframe, region, replacement method and eligibility are based on the manufacturer's terms, serial numbers and actual supply contracts, and the company's service offerings have not yet been confirmed.
