Key Architecture Highlights
- Processor platform: 2 x NVIDIA Vera processors (Nvidia MGX™ Vera C2)
- Memory support: 16 x SOCAMM2 96GB (up to LPDDR5X 9600 MT/s)
- Storage configuration: 8 x E1.S hot-swap drive bays (PCIe Gen6)
Applications
- AI training and inference
- High-performance computing
- Data center
Engineering Parameters
| Processor platform | 2 x NVIDIA Vera processors (Nvidia MGX™ Vera C2) |
|---|---|
| Memory support | 16 x SOCAMM2 96GB (up to LPDDR5X 9600 MT/s) |
| Expansion slots | Total 5 expansion slots 2 x PCIe x16 slots (Gen6 x16 link, FHFL) for dual-slot GPU cards 1 x PCIe x16 slot (Gen6 x16 link, FHFL) for DPU/NIC card 2 x PCIe x16 slots (Gen6 x16 link, HHHL) for NIC card |
| Storage configuration | 8 x E1.S hot-swap drive bays (PCIe Gen6) |
| Network interfaces | 1 x management LAN port (RJ45) |
| GPU Supports | Support up to 2 x dual-slot GPU cards |
| Rear interfaces | 1 x USB Type-C port 1 x USB Type-C ports for UART 1 x RJ45 management LAN port |
| Chassis form factor and dimensions | Chassis dimensions: 900mm x 438mm x 88mm (MGX 2U Chassis) 35.4" x 17.2 x 3.5" chassis form factor:2U |
| Weight | Net Weight: 40 Kg Gross Weight: 52 Kg |
| Power supply specifications | 2+2 Redundant 2000W 80 PLUS Titanium Power Supply |
| Operating environment | Operating temperature*: 10°C~35°C Non-operating temperature: -40°C~70°C Non-operating humidity: 20%~95% (Non-condensing) *Support 10°C~25°C if system configured with 2 x 600W GPU cards |
Warranty
Public manufacturer information does not specify the warranty term applicable to our supply channel. The supply region, channel and actual warranty service are confirmed in the supply contract.
