Key Architecture Highlights
- Processor platform: 2 x Socket 6th Intel® Xeon® Processor Scalable Family (Up to 350W)
- Storage configuration: Optional Kits: -Broadcom MegaRAID 9540-8i
- Network interfaces: 2 x 10 Gigabit LAN ports (Intel X710-AT2 Controller) 1 x Management Port
Applications
- AI training and inference
- High-performance computing
- Data center
Engineering Parameters
| Processor platform | 2 x Socket 6th Intel® Xeon® Processor Scalable Family (Up to 350W) |
|---|---|
| Memory support | Total Slots: 32 (8 channel per CPU, 16 DIMM per CPU) Capacity: Maximum up to 4TB per CPU socket Memory Type: DDR5 6400 RDIMM/ 3DS RDIMM (2DPC) Memory Size: 128GB, 96GB, 64GB * Refer to support page for more information |
| Expansion slots | SKU1: 4 x PCIe Gen5 slots [PCIe Switch directly] -4 x PCIe Gen5 x16 link SKU2: 5 x PCIe Gen5 slots [PCIe Switch directly] -4 x PCIe Gen5 x16 link -1 x PCIe Gen5 x8 link (Raid Only) *Support PCIe x16 link support DPU For Raid card to connect storage |
| Storage configuration | Optional Kits: -Broadcom MegaRAID 9540-8i |
| Network interfaces | 2 x 10 Gigabit LAN ports (Intel X710-AT2 Controller) 1 x Management Port |
| GPU Supports | NVIDIA HGX B300 288GB 8-GPU Baseboard |
| Front interfaces | 2 x USB 3.2 ports 1 x VGA port 2 x 10GbE RJ45 LAN port 1 x RJ-45 Mgmt LAN port |
| Supported operating systems | Please find the latest OS support from https://servers.asus.com/support/os |
| Management features | ASUS Control Center On-Board ASMB12-iKVM |
| Chassis form factor and dimensions | The chassis dimensions are: 945mm * 447mm * 394.5 mm Chassis form factor: 9U |
| Weight | Net Weight kg (CPU, DRAM & HDD not included): 120kg Gross Weight kg(CPU, DRAM & HDD not included, Packing include): 150kg |
| Power supply specifications | 5+5 3200W 80 PLUS Titanium Power Supply |
| Operating environment | Operation temperature: 10℃ ~ 35℃ Non operation temperature: -40℃ ~ 70℃ Non operation humidity: 20% ~ 90% ( Non condensing) |
Warranty
Public manufacturer information does not specify the warranty term applicable to our supply channel. The supply region, channel and actual warranty service are confirmed in the supply contract.
