Key Architecture Highlights
- Processor platform: 2 x Socket SP5 (LGA 6096) AMD EPYC™ 9004 Series (up to 400W) 4th Generation AMD EPYC Processors with AMD 3D V-Cache technology *Please consult sales for more details.
- Cooling system: The system fan is 4 cooling devices supported: Configuration #1 (Non-GPU support) 2U Standard Heatsink Configuration #2 (GPU support) 1U EVAC Heatsink
- Display features: Aspeed AST2600 64MB
Applications
- Enterprise computing
- Virtualization and cloud computing
- Data center
Engineering Parameters
| Processor platform | 2 x Socket SP5 (LGA 6096) AMD EPYC™ 9004 Series (up to 400W) 4th Generation AMD EPYC Processors with AMD 3D V-Cache technology *Please consult sales for more details. |
|---|---|
| Memory support | Total Slots : 24 (12-channel per CPU, 1 DIMM per CPU) Capacity : Maximum up to 3072GB per socket Memory Type : DDR5 4800/4400 RDIMM/ 3DS RDIMM Memory Size : 128GB, 64GB, 32GB RDIMM 128GB, 64GB, 32GB 3DS RDIMM * Refer to www.asus.com/support for more information |
| Expansion slots | Configuration #1 (Non-GPU support) Up to 9 x Expansion slots + 1 x internal RAID slot 6 x PCIe Gen5 x8 or 3 x PCIe Gen5 x16 (FHFL) 2 x PCIe Gen5 x8 or 1 x PCIe Gen5 x16 or 1 x OCP3.0 (FHFL) 1 x PCIe Gen5 x16 (LPHL) 1 x PCIe Gen4 x8 (LP, internal) Configuration #2 (GPU support) Up to 9 x Expansion slots + 1 x internal RAID slot 6 x PCIe Gen5 x8 or 3 x PCIe Gen5 x16 (FHFL) 2 x PCIe Gen5 x8 or 1 x PCIe Gen5 x16 (FHFL) 1 x PCIe Gen5 x16 (LPHL) 1 x PCIe Gen4 x8 (LP, internal) |
| Storage configuration | SATA Controller : 8 x SATA 6Gb/s ports 2 x M.2 connectors (SATA 6Gb/s & PCI-E Gen4 x4 link) SAS Controller : Braodcom HBA CARD 9500-16i (Optional) Broadcom MegaRAID 9540-8i (Optional) Broadcom MegaRAID 9560-16i (Optional) NVMe Controller : SupremeRAID™ from Graid SR1001 (support up to 4 NVMe) (Optional) SupremeRAID™ from Graid SR1000 (support up to 12 NVMe) (Optional) SupremeRAID™ from Graid SR1010 (support up to 12 NVMe) (Optional) |
| Drive bays | Configuration #1 (Non-GPU support) Front Bays: 12 x 3.5”/2.5" hot-swap drive bay 4 x NVMe/SAS* + 4 x NVMe/SATA/SAS* + 4 x SATA/SAS* Rear Bays (Optional): 2 x 2.5" hot-swap drive bays Support 2 x NVMe Configuration #2 (GPU support) 12 x 3.5”/2.5" hot-swap drive bay 4 x NVMe/SAS* + 4 x NVMe/SATA/SAS* + 4 x SATA/SAS* *HBA/RAID card is required to support SAS hard drives Front Bays: 12 x 3.5" Hot-Swap drive bays Support up to 4NVMe/SAS* + 4NVMe/SATA/SAS* + 4SATA/SAS* Rear Bays: 2 x 2.5" Hot-Swap drive bays (Optional) Support 2NVMe *RAID card is required to support SAS hard drives. Will occupied 2 PCIe slots |
| Cooling system | The system fan is 4 cooling devices supported: Configuration #1 (Non-GPU support) 2U Standard Heatsink Configuration #2 (GPU support) 1U EVAC Heatsink |
| Network interfaces | Configuration #1 (Non-GPU support) 1 x Mgmt LAN 4 x1Gbe(Intel I350-AM4) RJ45 port (optional) or 2 x 10Gbe(Intel X710-AT2) RJ45 port (optional) Configuration #2 (GPU support) 1 x Mgmt LAN 2 x 10Gbe(Intel X710-AT2) RJ45 port (optional) |
Warranty
Public manufacturer information does not specify the warranty term applicable to our supply channel. The supply region, channel and actual warranty service are confirmed in the supply contract.
