Key Architecture Highlights
- Processor platform: Intel®Xeon® Processor Scalable Family
- Chipset: Intel® C741 Chipset
- Expansion slots: Up to 4 slots • 2 x PCIe Gen5 x8 link or 1 x PCIe Gen5 x16 link (FHFL) • 1 x PCIe Gen5 x16 (LP) • 1 x OCP 3.0 (optional)
Applications
- Enterprise computing
- Virtualization and cloud computing
- Data center
Engineering Parameters
| Processor platform | Intel®Xeon® Processor Scalable Family |
|---|---|
| Chipset | Intel® C741 Chipset |
| Memory support | Total slot: 32 (8-channel per CPU, 16 DIMM per CPU) Capacity: Maximum up to 4TB Memory type: 4th: 4800 MHz (1DPC)/ 4400 MHz (2DPC) 5th: 5600/4800 MHz (1DPC)/4400(2DPC) Memory size: 64GB, 32GB, 16GB RDIMM 256GB, 128GB RDIMM 3DS * Refer to www.asus.com/support for more information |
| Expansion slots | Up to 4 slots • 2 x PCIe Gen5 x8 link or 1 x PCIe Gen5 x16 link (FHFL) • 1 x PCIe Gen5 x16 (LP) • 1 x OCP 3.0 (optional) |
| Storage configuration | 24 x 2.5" hot-swap bay 12x NVMe + 12x SATA/SAS* or 12x NVMe + 12x NVMe/SATA/SAS* (*HBA/RAID card is required to support SAS hard drives) EDIT |
| Drive bays | 24 x 2.5" hot-swap bay 2 x M.2 slot |
| Cooling system | The system fan: 4 cooling support: Standard |
| Network interfaces | 4 x1Gbe(Intel I350-AM4) RJ45 port or 2 x 10Gbe(Intel X710-AT2) RJ45 port |
| Display features | Aspeed AST2600 64MB |
| Front interfaces | 2 x USB 3.2 Gen1 ports |
| Rear interfaces | 2 x USB 3.2 Gen1 ports 1 x VGA port 1 x RJ-45 Management LAN port 2 x 10G or 4 x 1G RJ-45 GbE LAN port (optional) |
| Chassis form factor and dimensions | Chassis dimensions: 840mm x 447mm x 88mm chassis form factor:2U |
| Weight | 36 kg |
| Power supply specifications | 1+1 Redundant AC: 2600W/1600W 80 PLUS Titanium/ Platinum Power Supply |
Warranty
Public manufacturer information does not specify the warranty term applicable to our supply channel. The supply region, channel and actual warranty service are confirmed in the supply contract.
