Key Architecture Highlights
- Processor platform: Intel®Xeon® Processor Scalable Family
- Expansion slots: Total 4 expansion slots 2 x PCIE Gen5 x16 (FHHL) 2 x OCP3.0 Gen5 x16 (SFF)
- Cooling system: The system fan: 8 coolers supported: 1U EVAC Heatsink*2
Applications
- Enterprise computing
- Virtualization and cloud computing
- Data center
Engineering Parameters
| Processor platform | Intel®Xeon® Processor Scalable Family |
|---|---|
| Memory support | Total slot: 32 (8-channel per CPU, 16 DIMM per CPU) Capacity: Maximum up to 8TB Memory type: 6th: 6400MHz (1DPC) Memory size: 128GB, 96GB, 64GB, 32GB, 16GB RDIMM 256GB RDIMM 3DS * Refer to ASUS server AVL for latest update |
| Expansion slots | Total 4 expansion slots 2 x PCIE Gen5 x16 (FHHL) 2 x OCP3.0 Gen5 x16 (SFF) |
| Drive bays | 4x 2.5” hot-swap drive bays Support 4x NVMe/SATA*/SAS* *SATA/SAS SSDs only. HDDs are not supported. *HBA / RAID card is required to support SATA/SAS SSDs. 2 x M.2 Gen5 x2 (2280/2260)(VROC required for RAID) |
| Cooling system | The system fan: 8 coolers supported: 1U EVAC Heatsink*2 |
| Network interfaces | 1 x Management Port |
| Display features | Aspeed AST2600 64MB |
| Rear interfaces | 2 x USB 3.2 Gen1 ports 1 x Mini-DP port 1 x RJ-45 Management LAN port 1 x Debug port |
| Supported operating systems | Please find the latest OS support from https://servers.asus.com/support/os |
| Management features | On-Board ASMB12-iKVM for KVM-over-IP ASUS Control Center Enterprise (Classic C)(Optional) |
| Chassis form factor and dimensions | The chassis dimensions are: 821.7 L) x 483 W) x 43.2 H) mm 32.35 L) x 19 W) x 1.7 H) inch chassis form factor :1U |
| Weight | Net Weight : 13.81KG Gross Weight : 16.71KG |
| Power supply specifications | 1+1 Redundant 2000W 80 PLUS Titanium/Platinum PSU Rating: 100-127V~/220-240V~, 12A/10A (x2), 50/60Hz |
| Operating environment | Operation temperature: 10℃ ~ 35℃ Non operation temperature: -40℃ ~ 60℃ Non operation humidity: 20% ~ 90% (Non condensing) |
Warranty
Public manufacturer information does not specify the warranty term applicable to our supply channel. The supply region, channel and actual warranty service are confirmed in the supply contract.
