Key Architecture Highlights
- Processor platform: Intel®Xeon® Processor Scalable Family
- Chipset: Intel® C741 Chipset
- Storage configuration: 4 x 3.5" hot-swap bay 4 x NVMe/SATA/SAS* (HBA//RAID card is required to support SAS hard drives)
Applications
- Enterprise computing
- Virtualization and cloud computing
- Data center
Engineering Parameters
| Processor platform | Intel®Xeon® Processor Scalable Family |
|---|---|
| Chipset | Intel® C741 Chipset |
| Memory support | Total slot: 32 (8-channel per CPU, 16 DIMM per CPU) Capacity: Maximum up to 4TB Memory type: 4th: 4800 MHz (1DPC)/ 4400 MHz (2DPC) 5th: 5600/4800 MHz (1DPC)/4400(2DPC) Memory size: 64GB, 32GB, 16GB RDIMM 256GB, 128GB RDIMM 3DS * Refer to www.asus.com/support for more information |
| Expansion slots | Configuration #1 (Non-GPU support) Up to 3 x PCIe Gen5 slots + 1 x internal RAID slot 1 x PCIe Gen5 x16 (FHFL) 1 x PCIe Gen5 x16 or 1 x OCP3.0 (FHFL) 1 x PCIe Gen5 x16 (LP) 1 x PCIe Gen4 x8 (LP, internal) Configuration #2 (GPU support) Up to 3 x PCIe Gen5 slots + 1 x internal RAID slot 1 x PCIe Gen5 x16 (FHFL) 1 x PCIe Gen5 x16 (FHFL) 1 x PCIe Gen5 x16 (LP) 1 x PCIe Gen4 x8 (LP, internal) |
| Storage configuration | 4 x 3.5" hot-swap bay 4 x NVMe/SATA/SAS* (HBA//RAID card is required to support SAS hard drives) |
| Drive bays | 4 x 3.5" hot-swap bay 2 x M.2 slot |
| Cooling system | The system fan is 9 cooling devices supported: Configuration #1 (Non-GPU support) 1U Standard Heatsink Configuration #2 (GPU support) 1U EVAC Heatsink |
| Network interfaces | Configuration #1 (Non-GPU support) 1 x Mgmt LAN 4 x1Gbe(Intel I350-AM4) RJ45 port (optional) or 2 x 10Gbe(Intel X710-AT2) RJ45 port (optional) Configuration #2 (GPU support) 1 x Mgmt LAN 2 x 10Gbe(Intel X710-AT2) RJ45 port (optional) |
| Display features | Aspeed AST2600 64MB |
| Front interfaces | 2 x USB 3.2 Gen1 ports |
| Rear interfaces | 2 x USB 3.2 Gen1 ports 1 x VGA port 1 x RJ-45 Management LAN port 2 x 10G or 4 x 1G RJ-45 GbE LAN port (optional) |
| Chassis form factor and dimensions | Chassis dimensions: 842.5mm x 439.5mm x 44mm chassis form factor:1U |
| Weight | 22.56kg |
| Power supply specifications |
Warranty
Public manufacturer information does not specify the warranty term applicable to our supply channel. The supply region, channel and actual warranty service are confirmed in the supply contract.
