Key Architecture Highlights
- Processor platform: 1 x Socket SP5 (LGA 6096) 5th Generation AMD EPYC Processors or 4th Generation AMD EPYC Processors AMD EPYC™ 9005/9004 Series Processors (Air cool with STD HS up to 360W)
- Storage configuration: Storage Controller : CPU Integrated Optional kits Controller : Broadcom Mega RAID 9560-16i ASUS PIKE II 3008-8i 8-port SAS 12G HBA card
- Network interfaces: 1 x Dual Port Intel I350-AM2 GbE LAN Controller 1 x Management Port
Applications
- Enterprise computing
- Virtualization and cloud computing
- Data center
Engineering Parameters
| Processor platform | 1 x Socket SP5 (LGA 6096) 5th Generation AMD EPYC Processors or 4th Generation AMD EPYC Processors AMD EPYC™ 9005/9004 Series Processors (Air cool with STD HS up to 360W) |
|---|---|
| Memory support | 24 x DIMM slots with AMD EPYC™ 9005 series processors DDR5 6400/5600 RDIMM/3DS RDIMM Maximum 3,072GB 2DPC (1 of 2) up to 5200 with "6400 RDIMM", other 4800 2DPC (2 of 2, 1R+1R ) up to 4400, with "6400 RDIMM", other 4000 2DPC (2 of 2, 2R+2R ) up to 4000, with "6400 RDIMM", other 3600 with AMD EPYC™ 9004 series processors DDR5 4800 RDIMM/ 3DS RDIMM Maximum 3,072GB 2DPC (1 of 2) up to 4800, 2DPC (2 of 2, 1R+1R ) up to 4000 2DPC (2 of 2, 2R+2R ) up to 3600 * Refer to support page for more information |
| Expansion slots | 16 NVMe configuration SKU: Up to 5 PCIe Gen5 slots + 1 OCP3.0 2 x PCIe Gen5 x16, FHFL or 4 x PCIe Gen5 x8, FHFL 1 x PCIe Gen5 x8, LP 1 x OCP 3.0 Slot ( (PCIe Gen5 x16) 24 NVMe configuration SKU: Up to 1 PCIe Gen5 slots + 1 OCP3.0 1 x PCIe Gen5 x8, LP 1 x OCP 3.0 Slot ( (PCIe Gen5 x16) |
| Storage configuration | Storage Controller : CPU Integrated Optional kits Controller : Broadcom Mega RAID 9560-16i ASUS PIKE II 3008-8i 8-port SAS 12G HBA card |
| Drive bays | Front bays: 16 NVMe configuration SKU: 24 x 2.5” hot-swap drive bays Support 16x NVMe + 8 SAS/SATA *RAID/PIKE cable is needed for 8 SAS/SATA 24 NVMe configuration SKU: 24 x 2.5” hot-swap drive bays Support 24x NVMe Rear bays:2 x 2.5” SATA hot-swap drive bays 2 x M.2 connectors |
| Network interfaces | 1 x Dual Port Intel I350-AM2 GbE LAN Controller 1 x Management Port |
| Display features | Up to 4 single-slot or 2 double-slot GPU cards 16 NVMe configuration SKU: 4 single-slot or 2 double-slot GPU cards 24 NVMe configuration SKU: Can‘t support GPU |
| GPU Supports | Please find the latest GPU support from https://servers.asus.com/support/gpu |
| Front interfaces | 2 x USB 3.2 Gen1 ports |
| Rear interfaces | 2 x USB 3.2 Gen1 ports 1 x VGA port 1 x Management port 2 x 1GbE LAN ports |
| Supported operating systems | Please find the latest OS support from https://servers.asus.com/support/os |
Warranty
Public manufacturer information does not specify the warranty term applicable to our supply channel. The supply region, channel and actual warranty service are confirmed in the supply contract.
