Key Architecture Highlights
- Processor platform: 2 x Socket 4th Gen Intel® Xeon® Scalable processors (Up to 350W) 5th Gen Intel® Xeon® Scalable processors (Up to 350W)
- Chipset: Intel® C741 Chipset
- Network interfaces: 2 x 1 Gigabit LAN ports (Intel I350 Controller) 1 x Management Port
Applications
- AI training and inference
- High-performance computing
- Data center
Engineering Parameters
| Processor platform | 2 x Socket 4th Gen Intel® Xeon® Scalable processors (Up to 350W) 5th Gen Intel® Xeon® Scalable processors (Up to 350W) |
|---|---|
| Chipset | Intel® C741 Chipset |
| Memory support | Total Slots: 16 (8 channels per CPU, 8 DIMM per CPU) Capacity: Maximum up to 4TB per CPU socket Memory Type: 4th: DDR5 4800 MHz RDIMM/3DS RDIMM (1DPC) 5th: DDR5 5600/4800 MHz RDIMM/3DS RDIMM (1DPC) 512GB, 256GB, 128GB Intel® Optane™ persistent memory 300 series |
| Expansion slots | Rear: 4 x PCIe x16 slots (Gen5 x16 link, FH, FL) for dual-slot GPU cards or 8 x PCIe x16 slots (Gen5 x8 link, FH,FL) for single-slot GPU cards -2 x PCIe x16 slots (Gen5 x16 link, FH, HL) Front: 1 x PCIe x8 slot (Gen4 x8 link, LP, HL) |
| Storage configuration | 2 x 2.5” & 4 x 3.5“ Hot-swap Storage Bays SKU1: 2 x 2.5” SATA/SAS*/NVMe + 2 x 3.5” SATA/SAS*/NVMe + 2 x 3.5” SATA/SAS* SKU2: Build to order 2 x 2.5” SATA/SAS*/NVMe + 4 x 3.5” SATA/SAS*/NVMe (Occupy 1 x PCIe x8 link ) *SAS support required a HBA/RAID card. For SKU1 additional 2 x NVMe support required a RAID card. 1 x M.2 socket (Gen3 x4 link PCIe mode, up to 2280) |
| Network interfaces | 2 x 1 Gigabit LAN ports (Intel I350 Controller) 1 x Management Port |
| GPU Supports | Please find the latest GPU support from https://servers.asus.com/support/gpu |
| Front interfaces | 4 x USB 3.2 Gen1 ports |
| Rear interfaces | 2 x USB 3.2 Gen1 ports 2 x Gigabit LAN ports (RJ45) 1 x MAnagement port (RJ45) 1 x VGA port |
| Supported operating systems | Windows Server RedHat® Enterprise Linux SuSE® Linux Enterprise Server CentOS Ubuntu Vmware *Please find the latest OS support from https://servers.asus.com/support/os |
| Management features | ASUS Control Center ASUS ASMB11-iKVM (on-board) |
| Chassis form factor and dimensions | 800mm x 439.5mm x 88.9mm (2U) 31.50" x 17.30" x 3.50" |
| Weight | Net Weight: 26 Kg Gross Weight: 36.8 Kg |
Warranty
Public manufacturer information does not specify the warranty term applicable to our supply channel. The supply region, channel and actual warranty service are confirmed in the supply contract.
