Key Architecture Highlights
- Processor platform: 2 x AMD EPYC™ 9005/9004 Series Processors (Up to TDP 400W)
- Network interfaces: 2 x 10 Gigabit LAN ports (Intel X710-AT2 Controller) 1 x Management Por
- GPU Supports: Please find the latest GPU support from https://servers.asus.com/support/gpu
Applications
- AI training and inference
- High-performance computing
- Data center
Engineering Parameters
| Processor platform | 2 x AMD EPYC™ 9005/9004 Series Processors (Up to TDP 400W) |
|---|---|
| Memory support | Total Slots: 24x DDR5 DIMM slots, up to 6400MHz(1DPC) (12-channel per CPU, 12 DIMM per CPU) Capacity: Maximum up to 3TB Memory Type: DDR5 6400/5600 RDIMM 128GB, 96GB, 64GB *Refer to Asus server AVL for the latest update |
| Expansion slots | Up to 11 PCIe slots [89104 PCIe Switch directly] -8 x PCIe Gen5 x16 (LP, HL) – GPU group [89048 PCIe Switch directly] -1 x PCIe Gen5 x16 (FH, HL) – CPU 1 extension -1x PCIe Gen5 x8 (FH, HL) – CPU 1 extension [CPU directly] -1 x PCIe Gen5x16 (FH, HL) (CPU2) |
| Network interfaces | 2 x 10 Gigabit LAN ports (Intel X710-AT2 Controller) 1 x Management Por |
| GPU Supports | Please find the latest GPU support from https://servers.asus.com/support/gpu |
| Front interfaces | 4 x USB3.2 Gen1 ports, 1 x VGA port 2 x 10Gb RJ45 LAN module (Intel-x710 Based) 1 x Mgmt LAN 1 x locate button 1 x power button |
| Rear interfaces | 1 x locate button 1 x power button |
| Supported operating systems | Please find the latest OS support from http://www.asus.com/ |
| Management features | ASUS Control Center ASUS ASMB11-iKVM (on-board) |
| Chassis form factor and dimensions | Chassis dimensions: 885mm x 447mm x 306.65mm chassis form factor:7U |
| Weight | Net Weight: 108 Kg. Gross Weight: 142.4 Kg. |
| Power supply specifications | 5+1 Redundant 80 PLUS 3000W Titanium PSU |
| Operating environment | Operation temperature: 10℃ ~ 35℃ Non operation temperature: -40℃ ~ 70℃ Non operation humidity: 20% ~ 90% (Non condensing) |
Warranty
Public manufacturer information does not specify the warranty term applicable to our supply channel. The supply region, channel and actual warranty service are confirmed in the supply contract.
